Motherboard
| Supported processor frequency (max) |
1.333 GHz |
Other features
| Number of SATA connectors |
4 |
| Number of Parallel ATA connectors |
1 |
| Number of processors installed |
1 |
| Drive bays |
2 x 3.5", 2 x 5.25" |
| Expansion slots |
2 x PCI, \n1 x PCI-e x 1, \n1 x PCI-e x 16 |
Graphics
| Maximum graphics adapter memory |
384 MB |
Ports & interfaces
| DVI port |
Y |
| PS/2 ports quantity |
2 |
| Headphone outputs |
1 |
| S/PDIF out port |
Y |
| Microphone in |
Y |
| HDMI ports quantity |
1 |
| VGA (D-Sub) ports quantity |
1 |
Audio
| Audio system |
Realtek ALC887 |
Memory
| Maximum internal memory |
8 GB |
Networking
| Networking features |
Gigabit Ethernet |
Additionally
| Chipset |
Intel G41 Express |
| Graphics |
GMA X4500 |
| Ethernet LAN (RJ-45) ports quantity |
1 |
V6-P5G41H - Socket LGA 775, 1333/1066/800MHz FSB, 2 x DIMM Dual DDR2 1066/800/667 max. 8GB, 2 x PCI, 1 x PCI-e x 1, 1 x PCI-e x 16, Intel GMA X4500 max. 384M, 1 x ATA 100, 4 x SATA II, Gigabit Ethernet, 250W (PFC)
High definition Video and Audio supported
V6-P5G41H is the most economic Intel solution with HDMI and delivers optimized 3D graphics performance. It supports high definition content, full 1080P, and smooth playback of Blue-ray. Moreover, with theater-like HD 8 channel audio, it allows better entertaining enjoyment with high quality sound.
Support Microsoft DirectX10
It redefines gaming, multimedia and business experience, providing more vivid scene and also delivers exceptional performance with advanced hardware supports.
Support DDR2 1066MHz (O.C.)
While CPU is running under FSB 1333/1066, ASUS´ exclusive technology offers a choice of DDR2 1066 (O.C.) providing great performance for 3D graphics and other memory demanding applications.
Excellent connectivity with other peripherals
V6-P5G41H supports multiple display ports, HDMI, DVI, and D-sub, to provide rich connecting capability. Also it supports optical S/PDIF-out jack to connect external home theater audio systems.
ASUS Express Gate
ASUS Express Gate offers an optional Linux OS bootup that allows you to enjoy instant access to commonly used functions like accessing the Internet, VoIP, and Web emailing without entering Windows.
ASUS DriveClone Pro 5 (Continuously protect and back up your valuable data)
ASUS DriveClone Pro 5 can back-up users' data just in few seconds and recover it in few minutes. DriveClone Pro 5 is an always available recovery tool. It stores user data, applications and the operating system in the host-protected area of the hard drive. Users can easily recover system to any state without restore CDs. No need to worry about losing data due to virus attacks.
ASUS EPU-4 Engine
ASUS EPU - the world's first power saving engine, provides total system power savings by detecting current PC loadings and intelligently moderating power in real-time. EPU-4 Engine automatically provides the most appropriate power usage for the CPU, VGA card, hard drives and CPU cooler fan - helping save power and money.
