Technical details
Supported connectors |
RJ-45 |
Standard Power Panel
The most effective and handiest test instrument has always been the DVM (Digital Voltmeter). Now there is one designed for CAT5/6 Cables and Connectors!
POWER PANEL INLINE AND POWER PANEL TONE STAR MODELS
CAT5/6 DVM and Network/PoE Tester
Understanding what data and power is on a CAT5/6 cable is becoming increasingly important as cables are becoming crowded with a wide variety of data devices and power sources. In fact, knowing what is on a cable before plugging in can protect valuable equipment and speed up new installations. The Power Panel CAT5/6 DVM is the right tool at the right time because, once connected, it goes to work scanning each pin on a connector and displaying both the activity and the pair location. Whether it be network devices, phones or Power over Ethernet, all is displayed. And, if you are a VoIP phone of IP camera installer, you will find the Power Panel CAT5/6 DVM particularly useful because you will know if there is power and a data pair available for your equipment…. exactly what you need to make you device operate.
<b>4 POWER PANEL DVM MODELS TO CHOOSE FROM!</b>
- Standard unit (P/N POE1000): Packed with features for sensing what is on a CAT5/6 cable (switches, phones, PoE power) plus interacts with these devices.
- DSL unit (P/N POE1000DSL): All of the features of the Standard unit plus the ability to sense DSL tones.
- Inline unit (P/N POE1000IL): The most popular Power Panel CAT5/6 DVM model has all of the features of the Standard unit plus the ability to connect between 2 devices (“inline”). Inline connections allow passing PoE power to the device monitoring the device while it is ON. Plus the inline Power Panel measures and displays power draw (in watts).
- Tone Star unit (P/N POE1000ILT): All of the features of the inline unit (above) plus we add our full featured, filtered probe. The probe is used as a wire locator to audibly trace the tone placed on the wires by the Power Panel main unit. It features a tone button, volume control, ultrabright LED lighted tip, and 2 status LEDs: One to visually identify the tone and the other to warn you that there is 60hz present in the area. The probe is filtered to minimize fluorescent hum.
