显示器
| 显示器尺寸 |
15 " |
| HD 类型 |
Not supported |
| 响应时间 |
25 ms |
| 对比度 |
700:1 |
| 显示器分辨率 |
1024 x 768 pixels |
| 视角,水平 |
160 ° |
| 视角,垂直 |
140 ° |
| 显示器亮度 |
400 cd/m² |
| 显示器 |
LED |
端口 & 界面
| DVI端口 |
Y |
| DVI-D接口数量 |
1 |
| VGA(D-SUB)端口数量 |
1 |
人体工程学
| VESA 安装支架 |
Y |
| 高度调整 |
N |
| 屏幕显示 |
Y |
重量和尺寸
| 深度 |
32.8 mm |
| 宽度 |
362 mm |
| 重量 |
3800 g |
| 高度 |
288 mm |
多媒体
| 集成电视调谐器 |
N |
| 内置摄像头 |
N |
| 内置扬声器 |
N |
环境条件
| 储存温度范围 (T-T) |
-30 - 70 °C |
| 运行湿度范围(H-H) |
5 - 95% |
另外
| 产品色彩 |
Grey |
| 包括 AC 适配器 |
Y |
| 能源效率等级 |
Unspecified |
| 运行温度范围(T - T) |
-20 - 60 °C |
38.1 cm (15 ") LED, 1024 x 768, 400nits, CR 700:1, VGA, DVI, 3.8kg
15" 1024 x 768, VGA/DVI interface, Ultra Slim Touch Open Frame Monitor
The Advantech IDS-3115 Open Frame Monitor Series offer ultra slim design supporting a 15" 1024 x 768 pixels TFT LCD screen, with -20 ~ 60℃ wide operating temperature, and optional resistive touchscreen. The series supports rear and VESA mounting and is ideal for different embedded applications.
Features:
- 15" 1024 x 768 XGA LCD panel with LED backlight for 20% power saving and environmental protection
- 20~ 60° C operating temperature support
- 5-wires resistive touchscreen solution
- Combo touch interface of RS-232 and USB
- Dual signal interface with VGA and DVI
- Integrated bracket for easy installation
- Versatile mounting methods for Rear mounting and VESA mounting
- Anti-Reflective surface treatment for sunlight readable enhancement (optional)
- Ultra high brightness solution of 1200 nits for outdoor application (optional)
