视频
| 最大模拟分辨率 |
2048 x 1536 pixels |
| 最大数字分辨率 |
1600 x 1200 pixels |
端口 & 界面
| USB 连接器形状 |
USB Type-A |
| 控制台端口 |
USB A |
| 控制台 USB 端口数量 |
1 |
| PS/2连接埠数量 |
2 |
| 鼠标接口类型 |
USB, PS/2 |
| 键盘接口类型 |
USB, PS/2 |
| 视频接口类型 |
VGA |
另外
| 以太网路(RJ-45)连接接口数量 |
1 |
| 以太网连接器 |
Y |
8 x VGA, 2 x PS/2, USB, 2048 x 1536 px, 408.5 x 165 x 44 mm, 1U
The Prima TU 8-IP / Prima TU 16-IP gives users total control over its total server ports, from preboot stage
such as the BIOS-level CMOS setting up to the GUI applications and daily maintenance routines such as
power cycling (power control unit required). All these could be nicely done either on local console or using a
thin-client software viewer on any computer. The Prima TU 8-IP / Prima TU 16-IP is fully Web-enabled to
allow software upgrade and configuration upload/backup over the Web Management Interface.
Full-time DDC Support for best video compatibility
Prima TU 8/16-IP KVM Switch support Full-time DDC emulation that can guarantee a trouble-free video performance
during whatever KVM operations. Prima TU KVM Switch is per-port DDC emulation chip that can present the correct
DDC data to the requesting graphic card at all time, so that there will be no video problems such as arising from broken
or failed DDC communication.
Tree-chainable up to next level for scalability up to 128/256 computers
The Prima TU 8/16-IP is designed to be tree-chained with itself down to next downstream units to
provide a total maximum port capacity of up to 128/256 PCs.
Centralized Rackmount Management
The Prima TU 8/16-IP features a console port to connect your shared keyboard, video and mouse, and 8/16 PC ports to
connect to your computers/servers. The rackmount design offers a neat placement of the KVM Switch units on the rack
for centralized management and also for security enhancement that could be provided by a locked server room. You can
simply place it on desktop or mount it on a standard 19” rack for more secured and centralized management.
OSD Menu offers more intuitive and convenient control
The full-feature OSD menu function gives an intuitive menu-driven operation most users will find indispensable for a truly
convenient KVM switching experience. The Prima TU 8/16-IP provides features such as Auto Logout, Password
Protection and Firmware upgrade, etc.
USB and PS/2 interface support on both Console and PC Side
The USB PS/2 KVM Switch supports both USB interface and PS/2 interface on both console side and PC side. You can
use either PS/2 or USB keyboard/mouse on the console side as well on the PC side. It is especially useful when your
server room is inhabited with legacy computers with only PS/2 interfaces and also with newer computers equipped with
only USB interfaces.
