接口 | DB-9 RS-232, Smart-Slot |
---|---|
输入连接器类型 | Hard Wire 3 wire (1PH+N+G), Hard Wire 5-wire (3PH + N + G) |
输出连接器 | (1) Hard Wire 3-wire (H N + G)\n |
名义输出电压 | 230 V |
输出电压说明 | Configurable for 220: 230 or 240 nominal output voltage |
半载典型备用时间 | 20.2 min |
---|---|
全载典型备用时间 | 7.5 min |
替换电池盒 | SYBT5 |
电池类型 | Maintenance-free sealed Lead-Acid battery with suspended electrolyte: leakproof |
输出功率(瓦特-安培) | 12000 VA |
---|---|
输出功率 | 8400 W |
工作高度 | 0 - 3000 m |
---|
General Features:
Audible Alarms,
Automatic internal bypass,
Automatic restart of loads after UPS shutdown,
Automatic self-test,
Battery modules connected in parallel,
Cold-start capable,
Configurable for N+1 internal redundancy,
Disconnected battery notification,
Field-replaceable power distribution panel,
Frequency and voltage regulation,
Generator Compatible,
Hot-swappable batteries,
Hot-swappable intelligence modules,
Hot-swappable power modules,
InfraStruXure Manager Compatible,
Input Power Factor Correction,
Intelligent Battery Management,
LCD display,
Manageable external batteries,
Modular design,
Network manageable,
Plug-and-Play external batteries,
Power conditioning,
Power Modules connected in parallel,
Predictive failure notification,
Programmable Frequency,
Rack/Tower Convertible,
Redundant Intelligence Modules,
Removable input/output wiring tray,
Resettable circuit breakers,
Safety-agency approved,
Scalable Power Capacity,
Scalable runtime,
Shippable with modules installed,
SmartSlot,
User-replaceable batteries,
User-replaceable intelligence modules,
User-replaceable power modules.
