主板元件 | ATX |
---|---|
可支持的Linux操作系统 | Y |
主板芯片组系列 | Intel |
组件应用 | PC |
可支持内存时钟速度 | 1600, 1866, 2133 MHz |
---|---|
支持的内存类型 | DDR4-SDRAM |
内存电压 | 1.2 V |
内存通道支持 | Quad |
内存插槽类型 | DIMM |
支持RDIMM模块的容量 | 16GB, 32GB, 4GB, 8GB |
最大RDIMM内存 | 32 GB |
內存插槽数量 | 8 |
BIOS内存大小 | 128 MB |
---|---|
基本输入输出系统类型 | UEFI AMI |
ACPI的版本 | 1.1 |
串口数量 | 1 |
---|---|
迅雷 ™ (Thunderbolt™) 端口数量 | 1 |
耳机输出端口 | 1 |
麦克风/音频输入插孔 | Y |
DisplayPort 数量 | 1 |
USB 3.0(第 1代3.1)Type-A 端口数量 | 2 |
VGA(D-SUB)端口数量 | 1 |
USB 2.0接口 | 1 |
---|---|
ATX电源接头 | Y |
TPM(可信任安全平台模组)接口 | Y |
USB 3.0(第 1代3.1)连接器 | 1 |
IPMI 2.0插槽 | Y |
火线接口数量 | 1 |
SATA III连接器数量 | 6 |
CD/AUX音频输入 | Y |
前面板音频接头 | Y |
网路唤醒功能 | Y |
---|
PCI Express X 8(Gen 3.x)插槽 | 1 |
---|---|
PCI Express X16(Gen 3.x)插槽 | 4 |
Mini PCI Express(Gen 2.x)扩展插槽 | 1 |
图形适配器系列 | Aspeed |
---|
主板晶片 | Intel C612 |
---|---|
图形适配器 | AST2400 |
以太网连接器 | Y |
以太网路(RJ-45)连接接口数量 | 3 |
