背板输出端口
| COM接口数量 |
1 |
| VGA（D-SUB）端口数量 |
1 |
| 麦克风/音频输入插孔 |
Y |
| 耳机输出端口 |
1 |
| PS/2连接埠数量 |
2 |
性能
| 音频系统 |
Realtek ALC662 |
| 主板芯片组系列 |
NVIDIA |
| 组件应用 |
PC |
| 主板南桥 |
NVIDIA nForce 630a |
处理器
| 处理器热功耗（最大） |
95 W |
| 支持处理器前端总线 |
1000 MHz |
| SMP（适用于表面安装的封装形式）处理器的最大数量 |
1 |
内存参数
| 内存插槽类型 |
DIMM |
| 内存通道支持 |
Dual |
| 內存插槽数量 |
2 |
| 最大内部存储 |
16 GB |
| 无错误检测和更正 |
Y |
| 支持的内存类型 |
DDR3-SDRAM |
内置输入/输出系统
| 前面板音频接头 |
Y |
| 机箱防盗接口 |
Y |
| CPU风扇接口 |
Y |
| SATA II连接器数量 |
4 |
| 软盘驱动器接口 |
Y |
| USB 2.0接口 |
2 |
| ATX电源接头 |
Y |
| 机箱风扇接头数量 |
1 |
图像
| 图形适配器系列 |
NVIDIA |
| 板载图形适配器 |
Y |
| DirectX版本 |
9.0 |
基本輸出輸入系統/BIOS
| BIOS内存大小 |
8 MB |
| 基本输入输出系统类型 |
AMI |
扩展槽
| PCI Express x16 插槽 |
1 |
| PCI 插槽 |
2 |
| PCI Express × 1插槽 |
1 |
另外
| 主板晶片 |
NVIDIA nForce 630a |
| 以太网路(RJ-45)连接接口数量 |
1 |
| 以太网连接器 |
Y |
| 系统总线 |
2 GT/s |
| 图形适配器 |
GeForce 7025 |
Support up to 95W Socket AM3+ processors, Dual Channel DDR3, max 16 GB, 4 x SATA2 3.0 Gb/s, 8Mb AMI Legal BIOS
<b>Orbweb ME</b>
Your Personal Cloud, Easy and Always Connects
ASRock Cloud technology makes your mobile devices connect to your PC seamlessly and supports multi devices for accessing File Explorer cloud service simultaneously! We offer a one-year subscription to Orbweb.ME Professional version, a personal cloud service which is $49.99 per year. It allows you to get connected with your PC's files, music, photos, and video clips remotely with tablets anytime, anywhere. Plus an additional one-month upgrade to Orbweb.ME Ultimate package with Remote Desktop function is also available. Now, download Orbweb Me Host, enter ASRock Cloud promotion code "ASR2014B", ASRock's users are allowed to enjoy all services above.
<b>Personal Cloud for Everyone</b>
Cloud service should be simple and personal. Don't take time to upload the files to the public cloud again. Stop spending money on setting up another NAS device you don't know. Orbweb ME's file browser is your solution to zero adaption, managing your folders and files in the cloud. Accessing and exchanging files instantly among all of your PC and storages. All your folders and files are sitting just where you know they are.
<b>Media Library and Streaming</b>
Orbweb Personal's media library takes care of your media content. Organize all your photos, videos and music across your PCs and online storages. Diverse, intuitive and smart sorting help finding desired movies in few clicks. Progressive streaming lets you enjoy your music collection almost no download time. Web browser based and mobile app portal keep you connected in any device any time.
<b>Access File Explorer From Multiple Devices</b>
Orbweb ME allows you to access your own personal File Explorer from multiple devices, bringing your tablets, laptops and PC together. Forgot an important file in your computer at home which you need for the next meeting? Another hard day hiding in the office bathroom, missing your massive collection of funny videos and music clips? You can get it all by connecting your tablets or laptops to access File Explorer and immerse into the paradise in few seconds.
<b>Remote Desktop Anywhere</b>
Laying in the bedroom or sitting in the office, tablet in your hands just becomes smarter. Pick up any work sheet left in office or start any application from you home PC. Orbweb ME's remote desktop not only mobilized your PC but also empower your tablet. No matter the device, No matter the location, Orbweb ME always keeps your PC by you.
<b>Wake On WAN</b>
The latest technology that WOWs you with the ability to wake up your PC remotely over the internet. Turn your PC on/off only when you need to. Keep your PC healthy and save energy at the same time.
