性能
| 主板元件 |
Micro ATX |
| 音频系统 |
Realtek ALC662 |
背板输出端口
| 并口数量 |
1 |
| PS/2连接埠数量 |
2 |
| 耳机输出端口 |
1 |
| 麦克风/音频输入插孔 |
Y |
| COM接口数量 |
1 |
| VGA（D-SUB）端口数量 |
1 |
其他功能
| 操作特性 |
WOL @ PME, WOR @ PME, PXE |
| 专用功能部件 |
CrashFree BIOS 2\nASUS EZ Flash \nASUS Q-Fan\nMyLogo |
处理器
| SMP（适用于表面安装的封装形式）处理器的最大数量 |
1 |
内置输入/输出系统
| USB 2.0接口 |
2 |
| S/PDIF输出端口 |
Y |
| 串列ATA连接器数量 |
2 |
| 并行ATA连接器 |
1 |
| ATX电源接头 |
Y |
| 软盘驱动器接口 |
Y |
| CD/AUX音频输入 |
Y |
| CPU风扇接口 |
Y |
| 机箱防盗接口 |
Y |
| 机箱风扇接头数量 |
1 |
| EATX电源接头数量 |
1 |
| 前面板音频接头 |
Y |
扩展槽
| 扩展插槽 |
1x PCIe x16\n1x PCIe x1\n2x PCI 2.2 |
另外
| 主板晶片 |
VIA P4M900 |
| 以太网路(RJ-45)连接接口数量 |
1 |
LGA775 Pentium CPU, DDR2 667/533, PCI-E
Intel LGA775 Pentium 4 CPU
This motherboard supports the latest Pentium 4 CPU from Intel in LGA775 package. With 1066/ 800/ 533MHz FSB, Hyper-Threading Technology and core-speeds up to 3.6GHz and beyond, Intel´s LGA775 Pentium 4 is one of the fastest desktop processors to date.
Intel Core™2 Duo
This motherboard supports the latest Intel® Core™2 processors in LGA775 package. With new Intel® Core™ microarchitecture technology and 1066 / 800 MHz FSB, Intel® Core™2 processor is one of the most powerful and energy efficient CPUs in the world.
Support Dual-Core CPU
This motherboard supports Intel® Pentium® D/Pentium® 4/Celeron® dual-core processors built on the 65-nanometer (nm) process technology with copper interconnect. Dual-core processors contain two physical CPU cores with dedicated L2 caches to meet demands for more powerful processing. Intel®´s 65nm process is the most advanced chip manufacturing technology, delivering breakthrough performance, enhanced media experience, and low power consumption. Intel® 65nm dual-core processors utilize the latest package technologies for a thinner, lighter design without compromising performance.
Single-Channel DDR2
DDR2 is the next generation memory technology to replace the current DDR. With initial speeds from 667MHz, DDR2 memory provides bandwidth up to 5.3GB/s.
Powerful Integrated Graphics
The P5VD2-VM SE delivers powerful integrated 2D and 3D graphics engine that provides hight performance along with functionality and value.
PCI Express Architecture
PCI Express is the latest I/O interconnect technology that will replace the existing PCI. With a bus bandwidth 4 times higher than that of AGP 8X interface, PCI Express x16 bus performs much better than AGP 8X in applications such as 3D gaming. PCI Express x1 also outperforms PCI interface with its exceptional high bandwidth up to 500MB/s.
High Definition Audio
Enjoy six-end sound system on your PC! The onboard 6-channel HD audio (High Definition Audio, previously codenamed Azalia) CODEC enables high-quality 192KHz/24-bit audio output, multi-streaming feature.
SATA 3Gb/s RAID
The VIA VT8237S chipsets incorporate two SATA 3Gb/s ports with high performance RAID functions in RAID 0, 1 and JBOD. This motherboard is the ideal solution to enhance hard disk performance and data back up protection without the cost of add-on cards.
ASUS CrashFree BIOS 2
The CrashFree BIOS2 feature now includes the BIOS auto-recovery function in a support CD. Users can reboot their system through the support CD when a bootable disk is not available, and go through the simple BIOS auto-recovery process. ASUS motherboards now enable users to enjoy this protection feature without the need to pay for an optional ROM.
ASUS EZ Flash
EZ Flash is a user-friendly BIOS update utility. Simply press the predefined hotkey to launch this tool and update BIOS from a USB flash disk before entering the OS. You can update your BIOS only in a few clicks without preparing an additional floppy diskette or using an OS-based flash utility.
ASUS Q-Fan
ASUS Q-Fan technology intelligently and automatically adjusts CPU fan speeds according to system load and temperature, enabling users to work in a distraction-free environment with minimal noise.
Green ASUS RoHS Compliant
The motherboard and its packaging comply with the European Union´s Restriction on the use of Hazardous Substances (RoHS). This is in line with the ASUS vision of creating environment-friendly and recyclable products and packaging to safeguard consumers´ health while minimizing the impact on the environment.
