数据传输
| MAC 地址表 |
8000 entries |
| 存储转发 |
Y |
设计
| 外壳材料 |
Metal |
| 液晶显示器指示灯 |
Link, Power, Speed, Status, System |
| 国际保护（IP）代码 |
IP30 |
| 认证 |
CE, FCC, RoHS |
联网
| 自动 MDI / MDI - X 检测功能 |
Y |
| 网络标准 |
IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z, IEEE 802.3 |
| 流量控制支持 |
Y |
| 10G支持 |
N |
| 全双工传输 |
Y |
能量控制
| 输入电压 |
18 - 36 V |
| 功耗（一般操作） |
20 W |
环境条件
| 运行湿度范围(H-H) |
0 - 95% |
| 储存温度范围 (T-T) |
-40 - 80 °C |
端口 & 界面
| 接线端子台端口 |
Y |
| 基本交换 RJ-45 以太网端口数量 |
26 |
| 基本交换 RJ-45 以太网端口类型 |
Fast Ethernet (10/100) |
| 以太网铜缆技术 |
100BASE-TX, 100BASE-T, 10BASE-T |
性能
| 程序包缓冲区内存 |
0.256 MB |
| 平均故障间隔时间 |
200000 h |
重量和尺寸
| 深度 |
220 mm |
| 宽度 |
443 mm |
| 高度 |
44 mm |
另外
| 运行温度范围（T - T） |
-10 - 60 °C |
Fast Ethernet, 26xRj-45, 256Kb Packet Buffer Memory, 8K MAC, 10/100BASE-T(X), 18-36V, 20W IP30, Metal, 443x44x220mm, 1U Rack, Blue
INDUSTRIAL GRADE, UNMANAGED ETHERNET SWITCHES - WITH GIGABIT OPTIONS
ESW600 Series Industrial Grade, 26 Port, Unmanaged, 10/100 Ethernet switches - with Gigabit options
B&B Electronics’ industrial hardened rack mount Ethernet switches are designed with harsh, rugged environment applications in mind. They are the ideal communications solutions for traffic control, water management, and warehousing.
Functional Description
B&B Electronics Elinx ESW626 family of unmanaged Industrial rackmount Ethernet switches have been designed to meet light Industrial communication requirements. This family offers several configuration options ranging from 26 ports all RJ45 copper to RJ45 copper with multi mode, single mode, and or combo SFP gigabit ports.
Fiber Options
Choose fiber optic ports for long distance runs or applications that require extreme noise immunity. Both multimode and single-mode fiber options are available. The factory installed fiber ports support 100BaseFX speeds. Some models support an optional combo SFP slot which can be used for applications requiring gigabit speeds over fiber networks.
Gigabit
Gigabit ports are typically used for backhaul connectivity or with IP cameras. Models with gigabit options are designed with combo ports. A combo port consists of both: a copper 10/100/1000 port and a gigabit SFP port. The gigabit SFP modules are optional items. If fiber optic connections with gigabit speeds are required, choose the appropriate SFP module. Shown below, and add it to your order. Note that the gigabit combo ports will default to the copper connection, once an SFP module is installed the copper gigabit port will be disabled and the switch will utilize the SFP port for traffic.
