能量控制
| 输入工作电压(最大值) |
258 V |
| 输入工作电压(最小值) |
180 V |
| 最大电流 |
16 A |
| 电源输入频率 |
50/60 Hz |
| 输出功率(瓦特-安培) |
3000 VA |
性能
| 输出传送时间(最小值) |
9 ms |
| 输出传送时间(最大值) |
12 ms |
16 A, 220/230/240 V AC, 180 - 258 v AC, 50 - 60 Hz, 9 - 16 ms, 2 x IEC C20, 1 x IEC C19, 8 x IEC C13, 438 x 330 x 44 mm, 5 kg, ATS
PowerWalker ATS (Automatic Transfer Switch) also known as STS (Static Transfer Switch) is designed with two independent power inlets to supply power to the load from primary power source. Should primary power source fail, the secondary will automatically backup the connected
equipment without any interruption. The transfer time from one to another is seamless to the connected equipment. After switching to a secondary power source, the ATS can also switch power back to the primary input when power to the primary input is restored.
