产品特点
电缆标准 |
Cat6 |
电缆屏蔽层 |
U/UTP (UTP) |
导体类型 |
Solid |
Cat 6 550 MHz UTP Solid Black Bulk Cable, 1000ft
Comprehensive Category 6 550MHz local area network cable utilizes 4 unshielded twisted pairs and solid (or stranded) bare copper 24 awg costruction. UL listing NEC,CMR/MPR. Nominal O.D. is 0.25 inches. Meets all requirements as set forth in the Telecommunications Industry Association's standard 568 & 570 recommendations.CM/CMG rated for single floor, general purpose use in walls and ceilings. Verified compliant with EIA/TIA standards by ETL. CSA listed.
- 4-pair unshielded twisted pair cable
- Polyethylene separator for enhanced NEXT, ELFEXT and RL Bandwidth
- 24AWG solid bare copper conductors for superior conductivity
- Meets EIA/TIA CAT6 specifications
- Durable, high-density polyethylene insulation, PVC jacket
- Ideal for 10Base-T(IEEE 802.3), 100Base-TX(IEEE 802.3u), 1000Base-TX, 100 Vg-AnyLAN(IEEE 802.12), Token Ring(IEEE 802.5), TP-PMD(ANSI X3T9.5), 350 Mbps CDDI, ATM 155, and all proposed Category 6 requirements for high-speed, full duplex, parallel transmission protocols
- CM/CMG rated for single floor, general purpose use in walls and ceilings
- Verified compliant with EIA/TIA standards by ETL
- CSA listed
