能量控制
输入工作电压(最大值) |
230 V |
输出功率(瓦特-安培) |
1500 VA |
输出工作电压(最大值) |
230 V |
输出功率 |
1000 W |
端口 & 界面
串联接口 |
Y |
USB端口 |
Y |
交流电(AC)插座数量 |
8 AC outlet(s) |
SmartSlot 智能插槽 |
Y |
性能
自动重新启动 |
Y |
UPS 拓扑 |
Line-Interactive |
发声警报模式 |
Alarm when on battery, Fault, Low battery alarm, Overload alarm |
Smart-UPS,1000 W /1500 VA, Input 230V /Output 230V, Interface Port SmartSlot, USB
Highlights
- High online efficiency Reduces utility costs, generates less heat.
- Intuitive LCD interface Provides clear and accurate information in multiple languages with the ability to configure the UPS locally with easy to use navigation keys.
- Single switched outlet group Single outlet group that may be controlled separately from the UPS for discrete reboot of hung devices, sequenced on/off and non-critical load shedding.
- SmartSlot Customize UPS capabilities with management cards.
- Cold-start capable Provides temporary battery power when the utility power is out.
- Temperature-compensated battery charging Prolongs battery life by regulating the charge voltage according to battery temperature.
- Predictive replace battery date Dynamically provides the month and year when battery replacement is recommended to aide in long term maintenance planning.
- Energy meter Provides actual kilowatt hours of usage for energy conscious users.
- Pure sine wave output on battery Simulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics.
- Green mode Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.
Smart-UPS Features & Benefits
Availability
- Boost and Trim Automatic Voltage Regulation (AVR) Gives higher application availability by correcting low and high voltage conditions without using the battery (not available on all models).
- Intelligent battery management Maximizes battery performance, life, and reliability through intelligent, precision charging.
- Power conditioning Protects connected loads from surges, spikes, lightning, and other power disturbances.
- Temperature-compensated battery charging Prolongs battery life by regulating the charge voltage according to battery temperature.
- Automatic restart of loads after UPS shutdown Automatically starts up the connected equipment upon the return of utility power.
- Automatic self-test Periodic battery self-test ensures early detection of a battery that needs to be replaced.
- Disconnected battery notification Warns when a battery is not available to provide backup power.
Manageability
- Network manageable Provides remote power management of the UPS over the network.
- Audible alarms Actively let you know if the unit is on battery, if the battery is low or if there is an overload condition.
- LED status indicators Quickly understand unit and power status with visual indicators.
- Serial connectivity Provides management of the UPS via a serial port.
- USB connectivity Provides management of the UPS via a USB port (not available on all models).
- Disconnected battery notification Warns when a battery is not available to provide backup power.
Serviceability
- User-replaceable batteries Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)
- Hot-swappable batteries Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
- Predictive failure notification Provides early-warning fault analysis ensuring proactive component replacement.
- Resettable circuit breakers Enables a quick recovery from overload events.
- Battery failure notification Provides early-warning fault analysis on batteries enabling timely preventive maintenance
Adaptability
- Adjustable voltage-transfer points Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation.
- Adjustable voltage sensitivity Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications.
Safety
- Safety-agency approved Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.
