端口 & 界面
| 串口数量 |
1 |
| 布线技术 |
10/100/1000Base-T(X) |
| 串联接口 |
Y |
| USB2.0端口的数量 |
1 |
| USB端口 |
Y |
| SmartSlot 智能插槽 |
Y |
性能
| 波形 |
Sine |
| 液晶显示器指示灯 |
Y |
| 发声警报器 |
Y |
| UPS 拓扑 |
Double-conversion (Online) |
设计
| 机架容量 |
3U |
| 格式要素 |
Rackmount |
| 显示器 |
LED |
能量控制
| 输入工作电压（最大值） |
230 V |
| 输出功率（瓦特－安培） |
5000 VA |
| 输出工作电压（最大值） |
230 V |
| 输出功率 |
4500 W |
内容包装
| 捆绑软件 |
APC InfraStruXure Manager |
另外
| 产品色彩 |
Black |
| 以太网路(RJ-45)连接接口数量 |
1 |
Smart UPS SRT 5000VA RM - 4500 Watt
Features :
- LCD graphics display
- Text and mimic diagrams that display modes of operation, system parameters and alarms.
- 10/100 BaseT Connection
- Connect the device to a network using a 10 or 100 BaseT connection
- Green mode
- Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.
- Battery failure notification
- Provides early-warning fault analysis on batteries enabling timely preventive maintenance
Smart-UPS On-Line Features & Benefits :
- Availability
- Automatic internal bypass
- Supplies utility power to the connected loads in the event of a UPS power overload or fault.
- Scalable runtime
- Allows additional run time to be quickly added as needed.
- Intelligent battery management
- Maximizes battery performance, life, and reliability through intelligent, precision charging.
- Hot-swappable batteries
- Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
- Automatic restart of loads after UPS shutdown
- Automatically starts up the connected equipment upon the return of utility power.Temperature-compensated battery charging
- Prolongs battery life by regulating the charge voltage according to battery temperature.
- Manageability
- Network manageable
- Provides remote power management of the UPS over the network.
- InfraStruXure Manager Compatible
- Enables centralized management via the APC InfraStruXure Manager.
- SmartSlot
- Customize UPS capabilities with management cards.
- LED status indicators
- Quickly understand unit and power status with visual indicators.
- Serial connectivity
- Provides management of the UPS via a serial port.
- Adaptability
- Plug-and-Play external batteries
- Ensures clean, uninterrupted power to the loads when adding extra runtime to the UPS.
- Rack/Tower convertible
- Protects the initial investment in the UPS when migrating from tower to rack-mount environment.
- Flash upgradeable firmware
- Install maintenance releases of firmware remotely using FTP.
- Serviceability
- User-replaceable batteries
- Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)
- Automatic self-test
- Periodic battery self-test ensures early detection of a battery that needs to be replaced.
- Predicitive failure notification
- Provides early-warning fault analysis ensuring proactive component replacement.
- Disconnected battery notification
- Warns when a battery is not available to provide backup power.
- Audible alarms
- Provides notification of changing utility power and UPS power conditions
- Protection
- Frequency and voltage regulation
- Gives higher application availability by correcting poor frequency and voltage conditions without using the battery.
- Power conditioning
- Protects connected loads from surges, spikes, lightning, and other power disturbances.
- Input power factor correction
- Minimizes installation costs by enabling the use of smaller generators and cabling.
- Generator compatible
- Ensures clean, uninterrupted power to protected equipment when generator power is used.
- Cold-start capable
- Provides temporary battery power when the utility power is out.
- Resettable circuit breaker
- Easy recovery from overloads; no need to replace a fuse.
- Safety-agency approved
- Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.
In addition to legendary reliability and manageability, Smart-UPS have extremely high efficiency at low, medium and high load levels making them ideal for today's multi-core or virtualized servers that have varying load consumption. Rack mounted Smart-UPS are ideal for powering Blade or density optimized servers in a distributed power protection environment as the primary or redundant protection. Smart-UPS models have long been considered the benchmark for all network and server UPS's. Smart-UPS feature a 16-segment LED display, extended range automatic voltage regulation (AVR), and pure sine wave output on battery.
