其他功能
| 安装端口 |
RS-485 |
| 接口 |
10/100 Mbps Ethernet RJ-45 |
| 内置存储器 |
0.512 MB |
| 闪存 |
0.128 MB |
| 安全 |
FCC Class A/UL 1950/EN 60950/EN55022, Class A or B/EN55024/EN61000-3-2,3/EN50082-1,2 |
EtherLite 2 - 2-port RS-485 RJ-45 terminal server
The EtherLite family of network serial concentrators adds serial ports to an Ethernet network, eliminating the installation of serial adapters inside servers. It offers easy installation, and network efficiency and control at a low price per port. The EtherLite can be used in numerous
applications including retail/POS, process control and data collection.
A single TCP/IP session services the traffic from all ports, not the conventional one-sessionper-port method. This means less overhead at the host and less traffic on the Ethernet. In addition, the EtherLite ports appear as local TTY ports under UNIX and as native COM ports under Microsoft® Windows®. These locally administered ports allow full control of serial ports.
All EtherLite models feature real serial ports and are preconfigured for use with the RealPort driver. This makes the EtherLite simple to deploy and configure. Simply attach the units to a twisted-pair Ethernet segment, set the IP address and load the device driver under
UNIX or Windows. The simple instruction guide included with the EtherLite and automated procedures save valuable time.
The EtherLite supports port speeds up to 115 Kbps, ideal for handling all of today’s serial devices. Full hardware and software flow control is supported. All this performance is available for an extremely low price per port.
