性能
| NVIDIA® G-SYNC 技术配置 |
Y |
| DirectX版本 |
12.0 |
| OpenGL版本 |
4.5 |
| 纹理填充率（TFR） |
120.5 GT/s |
| Full HD |
Y |
| HDCP |
Y |
处理器
| 处理器频率 |
1506 MHz |
| 图形处理器系列 |
NVIDIA |
| 视频卡最大显示 |
4 |
| 处理器提高时钟速度 |
1708 MHz |
内存参数
| 图形适配器内存类型 |
GDDR5 |
| 内存带宽（最大） |
192 GB/s |
| 数据宽度 |
192 bit |
| 内存时钟速度 |
8008 MHz |
| 独立显卡适配器內存 |
6 GB |
端口 & 界面
| DVI-D接口数量 |
1 |
| 接口类型 |
PCI Express x16 3.0 |
| DisplayPort 数量 |
3 |
| HDMI端口数量 |
1 |
| DisplayPort版本 |
1.4 |
能量控制
| 补充电源连接器 |
1x 8-pin |
| 最低系统供电 |
400 W |
另外
| 图形处理器 |
GeForce GTX 1060 |
| 双dvi（互应式数字视频） |
Y |
Nvidia GTX 1060 6GB, GDDR5, 192bit, PCI-E 3.0 16x, 7680 x 4320, 1280 Pixel Pipelines, 1506 MHz Base Clock, 1708 MHz Boost Clock, 120.5GT/s Texture Fill Rate, DVI-D, DisplayPort, HDMI, 400W, 120W, 1 x 8 pin
NVIDIA GameStream Technology
Stream extreme GeForce GTX PC gaming experiences to portable device like NVIDIA SHIELD with super-smooth, low-latency performance.
OpenGL 4.5 Support
Supporting the latest standards in the OpenGL API.
VR Ready
Discover next-generation VR performance, the lowest latency, and plug-and-play compatibility with leading headsets-driven by NVIDIA VRWorks technologies.
NVIDIA GPU Boost 3.0
Dynamically maximizes clock speeds based on workload and allows enthusiast-class controls such as temperature target and fan controls, extra over-voltage headroom, and optimizations for water-cooling solutions. This allows gamers to push performance to new levels.
Vulkan API
A next generation graphics and compute API from Khronos Group that provides high-efficiency, cross-platform access to modern GPUs.
Max Digital Resolution - 7680x4320
DisplayPort 1.4 Ready supporting up to 7680x4320 resolution at 60Hz
Built for EVGA Precision XOC
This new version of Precision is built for the NVIDIA Pascal architecture and combines the best of EVGA Precision and EVGA OC Scanner to give you never before seen overclocking features and built in automatic tuning.
NVIDIA G-SYNC Ready
NVIDIA G-SYNC monitors feature revolutionary NVIDIA technology that eliminates screen tearing while also reducing input lag. The result is the smoothest, fastest, and most responsive gaming experience ever seen.
Simultaneous Multi-Projection
Simulates seperate viewports of the same scene giving improved performance in VR and improved display accuracy in NVIDIA Surround
NVIDIA Ansel
Revolutionary new 360-degree image capture.
Microsoft DirectX 12
Support for the latest Microsoft DirectX API to enable next-generation gaming.
PCI Express 3.0
This card is designed for the PCI Express 3.0 bus architecture, offering the highest data transfer speeds for the most bandwidth-hungry games and 3D applications. It also maintains backwards compatibility with existing PCI Express motherboards for the broadest support.
HDMI 2.0b, DisplayPort 1.4 and Dual-Link DVI
The latest standards in DisplayPort and HDMI interfaces.
EVGA ACX 3.0 Cooling
EVGA ACX 3.0 once again brings new and exciting features to the award winning EVGA ACX cooling technology. SHP 2.0 gives increased heatpipes and copper contact area for cooler operation, and optimized fan curve for even quieter gaming. Of course, ACX 3.0 coolers also feature optimized swept fan blades, double ball bearings and an extreme low power motor, delivering more air flow with less power, unlocking additional power for the GPU.
