性能
最大传输距离 |
80000 m |
类型 |
Network transmitter & receiver |
数据传输速度 |
11100 Mbit/s |
10Gbps, 300-pin, Small Form Factor, Tunable Transponder
While leading the industry with the most complete line of Small Form Factor (SFF) 300 PIN 10Gb/s transponders, Finisar has drawn on its expertise in the design and manufacturing of tunable optical transmission products to offer a compact module that provides nearly 60% reduction in surface area as compared to a larger form factor 300 PIN transponder while maintaining the same high standards of performance.
The SFF tunable transmitter is based on a standard 300 PIN MSA and features full C-and L-band tunability. This module is designed for metro and long haul applications and is available in configurations supporting +/-800 ps/nm or 1600 ps/nm of chromatic dispersion.
These products include the optical transmitter and receiver, laser bias and control circuitry as well as the electrical Mux/DeMux, which is 622/644/669 by 16 electrical single chip devices providing variable rate control for applications ranging from 9.953Gb/s (SONET) to 11.1Gb/s (10GE with FEC).
The optical receiver is based on a high sensitivity APD with typical sensitivity of -26.0dBm at a bit error rate (BER) 10-12. PIN based receiver designs are also available.
- Compliant with the 300 PIN Multi-Source Agreement (MSA)
- Integrated wavelocker on 50GHz
- Full C-band or L-band tunability
- Designed for metro and long haul applications
- 2.2 x 3.0 x 0.53 inch form factor
- Operating temperature -5°C to 70°C
- Multi-rate product applications support SONET, Ethernet, and FEC data rates
- 10Gb/s optical serial in/out with 622/644/669 by 16 electrical SERDES
- Internal microprocessor controlled
- I2C functionality
- APD or PIN receivers available
- Optical Internetworking Forum (OIF) compliant
