内存参数
| 图形适配器内存类型 |
GDDR5 |
| 独立显卡适配器內存 |
4 GB |
| 数据宽度 |
256 bit |
| 内存带宽（最大） |
173 GB/s |
性能
| NVIDIA® G-SYNC 技术配置 |
N |
| DirectX版本 |
11 |
| OpenGL版本 |
4.3 |
| 最高着色模型版本 |
5.0 |
| HDCP |
Y |
| 集成电视调谐器 |
N |
| PhysX |
N |
| NVIDIA 3D Vision |
Y |
| NVIDIA® GameWorks VR 平台 |
N |
端口 & 界面
| 接口类型 |
PCI Express 2.0 |
| DisplayPort 数量 |
2 |
| DVI-I接口数量 |
1 |
| DVI-D接口数量 |
1 |
处理器
| 图形处理器系列 |
NVIDIA |
| 峰值浮点性能（单精度） |
2100 Gflops |
| CUDA |
Y |
另外
| 双dvi（互应式数字视频） |
Y |
| 图形处理器 |
Quadro 5000 |
NVIDIA Quadro K5000 PCI-E Graphics Adapter
Do you require higher performance computation or graphics? NVIDIA Accelerators for HP servers seamlessly integrate GPU computing with select HP ProLiant Server series for scale-out computational and graphical deployments. Designed from the ground up for power-efficient, high performance supercomputing, they deliver dramatically higher application acceleration than a CPU-only approach for a range of scientific and commercial applications.
<b>Increased Performance to Solve Problems in Minutes Instead of Hours.</b>
The NVIDIA Accelerators family improves computational time which can dramatically reduce compute time for parallel applications, offering quicker time to solutions. By co-locating the NVIDIA Kepler™-based GRID GPUs and computational servers in the data center so that they share rather than transfer large datasets, display refresh-rates can be greatly improved. NVIDIA GRID GPUs are specifically designed to enable rich graphics in virtualized environments. Combined with the HP ProLiant WS460c Gen8 Graphics Server Blade with its converged infrastructure and workstation class end-user experience, the virtual desktop environment takes another leap forward. NVIDIA Accelerators can be configured and monitored by HP Insight Cluster Management Utility (CMU). Insight CMU will monitor and display GPU health such as temperature, and will also install and provision the GPU drivers and CUDA software.
