Product types: AV receiver, stereo receiver, network receiver
Speaker configurations: 9.2, 2.0
Output power per channel: 100 Watt
Technical specifications
Output power: 250 Watt
Output impedances: 4 Ohm, 16 Ohm, 8 Ohm
maximum sample rate: 192 kHz
Bitrate: 24 Bit
Connections
Analog audio inputs: 6x LINE In (Cinch/RCA, Stereo), 1x MM Phono In (Cinch/RCA, Stereo)
Analog audio outputs: Zone 2 (LINE Out, Cinch/RCA, Stereo), Zone 3 (LINE Out, Cinch/RCA, Stereo)
digital audio inputs: 1x S/PDIF IN (TOS-Link optical), 1x S/PDIF IN (Cinch/RCA coaxial)
HDMI ports: 7x HDMI In, 2x HDMI Out, HDMI-eARC
Video Connections: 1x Component In, 3x Composite In
Preamp outputs: 11.2 Surround (Cinch/RCA), 9.2 Surround (Cinch/RCA)
Front Connections: Headphone Output, HDMI Input, 1x Setup Microphone (Setup Mic), Aux In (3.5mm Jack, Stereo), Composite Video Input
Data connections: 1x Network (Ethernet), 1x USB 2.0 Type-A
Connections for control signals: 2x 12V Trigger IN, 3x 12V Trigger OUT, 1x Remote OUT, RS-232
additional connection: Antenna connection
Audio
Audio functions: IMAX Enhanced, aptX HD, aptX
Dolby Formats: Dolby Atmos, Dolby TrueHD, Dolby Height Virtualization, Dolby Surround
DTS Formats: DTS:X, DTS HD Master Audio, DTS, DTS Neural:X
Number of listening zones: 3
Video
Supported Resolutions: 8K (4320p), 4K (2160p), 1080p
Video Functions: 4K Pass-Through, 8K Pass-Through, Dolby Vision, HDR10, HDR10+, HLG (Hybrid Log Gamma), BT.2020 Support, Variable Refresh Rate, Deep Color, x.v.Color, HDCP 2.3
Connectivity
Network functions: Control via App
Wireless transmissions: WLAN, AirPlay 2, ChromeCast, Bluetooth, DTS Play-Fi, Roon
Streaming Services: Amazon Music, Deezer, Spotify, Tidal, Pandora, TuneIn
USB Interface: yes
Functions
automatic measurement: yes
Calibration System: Dirac Live
LipSync: yes
with remote control: yes
Reception areas: AM (MW), FM (UKW)
Number of station presets: 40
Ppower supply
Power consumption in operation: 750 Watt
Power Consumption Standby: 0,1 Watt
Smart Home
Voice Assistants: Amazon Alexa, Apple Siri, Google Assistant
Additional features
Dimensions: 435 x 174 x 377 mm
Weight: 11 kg
Housing property: Metal
Color: black
