内置输入/输出系统
通过内部接头的串行端口 |
Y |
USB 2.0接口 |
4 |
S/PDIF输出端口 |
Y |
SATA II连接器数量 |
2 |
并行端口,通过内部头 |
Y |
性能
主板元件 |
Mini ITX |
Motherboard ARK ID |
56455 |
主板芯片组系列 |
Intel |
英特尔® 双显示功能技术 |
Y |
组件应用 |
PC |
内存参数
可支持内存时钟速度 |
800, 1066 MHz |
错误更正代码 |
N |
支持的内存类型 |
DDR3-SDRAM |
内存通道支持 |
Single |
内存插槽类型 |
DIMM |
內存插槽数量 |
2 |
最大内部存储 |
4 GB |
背板输出端口
并口数量 |
1 |
串口数量 |
2 |
耳机输出端口 |
1 |
麦克风/音频输入插孔 |
Y |
HDMI端口数量 |
1 |
VGA(D-SUB)端口数量 |
1 |
扩展槽
Mini PCI Express插槽 |
2 |
PCI Express × 1插槽 |
1 |
PCI Express x1(Gen 2.x)插槽 |
1 |
图像
板载图形适配器 |
Y |
图形适配器系列 |
Intel |
分立图形支持 |
N |
技术细节
状态 |
End of Interactive Support |
SATA 连接口总数 |
2 |
处理器支持最大内存 |
4 GB |
格式要素 |
Mini-ITX |
处理器支持 ECC 功能 |
N |
板载图形适配器支持的显示器数量 |
2 |
USB版本 |
2.0 |
USB 端口数量 |
4.4 |
设计
产品系列 |
Desktop board |
产品系列 |
Intel desktop board with Intel Atom |
另外
主板晶片 |
Intel NM10 Express |
最大内部存储 |
4096 MB |
英特尔® 高保真音频技术 |
Y |
以太网路(RJ-45)连接接口数量 |
1 |
Intel Desktop Board DN2800MT, Intel Atom N2800, mini-ITX, Intel NM10 Chipset, DDR3-1066 (max. 4GB), GMA3650, VGA, HDMI, 2x SATA2, Gigabit Ethernet
Intel® Desktop Board DN2800MT is integrated with the new Intel® Atom™ processor D2800 and the Intel® NM10 Express Chipset to offer a thin mini-ITX desktop computer system. The board features a 10/100/1000 integrated Intel® LAN, 1080 high-definition playback with HDMI, and Intel® High Definition Audio (Intel® HD Audio).
With the new low-power silicon, the Intel Desktop Board DN2800MT can be used in chassis that require no fan for heat dissipation. This board is designed for ultra small form factor (~1 liter) and All-In-One chassis.
While this desktop board is small in size, it delivers a rich multimedia and Internet experience with the support of 1080 high-definition video playback.
