室内单元
| 室内机深度 |
208 mm |
| 室内机高度 |
270 mm |
| 室内机宽度 |
850 mm |
| 噪音水平(室内单元) |
56 dB |
| 室内机重量 |
8500 g |
| 室内机类型 |
Wall-mountable |
室外单元
| 室外机宽度 |
751 mm |
| 室外机深度 |
240 mm |
| 室外机高度 |
482 mm |
| 室外机重量 |
28000 g |
| 噪音水平(室外单元) |
64 dB |
技术细节
| Wi-Fi 控制系统 |
N |
| 制冷量(最大) |
8800 BTU/h |
| 制热量(最大) |
9500 BTU/h |
| 制冷介质重量 |
880 g |
| 类型 |
Split system air conditioner |
| 制冷剂 |
R410A |
720W, 700W, 56dB, 64dB, A++, A+, White
INDOOR UNIT
- Indoor unit dimensions. 270 A x 850 L x 208 P mm
- Box indoor unit dimensions 335 A x 900 L x 260 P mm
- Net/Gross weight indoor unit 8,5/11Kg
- Cooling capacity 8800BTU
- Heating capacity 9500BTU
- Noise level indoor unit DB(A): 56
- Remote control with LCD display
- Cooling efficiency class A++
- Heating efficiency class A+
- EER for cooling 3,61W/W
- COP for heating 4,00W/W
- Indoor unit with LED display
- Recomended area 9-18m2
- Heating power 700W
- Cooling power 720W
- Gas R410A/880g
OUTDOOR UNIT
- Outdoor unit dimensions. 482 A x 715 L x 240 P mm
- Box outdoor unit dimensions 530 A x 830 L x 315 P mm
- Net/Gross weight outdoor unit 28/30Kg
- Cooling capacity 8800BTU
- Heating capacity 9500BTU
- Noise level outdoor unit DB(A): 64
- Remote control with LCD display
- Cooling efficiency class A++
- Heating efficiency class A+
- EER for cooling 3,61W/W
- COP for heating 4,00W/W
- Indoor unit with LED display
- Recomended area 9-18m2
- Heating power 700W
- Cooling power 720W
- Gas R410A/880g
