技术细节
| 最大传输距离 |
70 m |
| 带宽 |
10.2 Gbit/s |
| 类型 |
AV receiver |
| 可支持的电缆类型 |
Cat5e, Cat6a, Cat6 |
端口 & 界面
| RS-232 输入端口 |
1 |
| RJ-45输入端口 |
1 |
| DC-IN插口 |
Y |
4K Compliant HDBaseT 70-Meter HDMI Extender w/ PoE - Receiver Only
The KanexPro HDBASE70POER is a 4K compliant receiver designed to work with HDBaseT enabled projectors and HDTVs . The receiver connects to HDMI for TV input, bi-directional IR and RS-232 extending out to a convenient Cat6a cable for expanded connectivity.
Fully compliant with HDCP and EDID management built-in, the HDBASE70POER delivers HD video up to 4K and digital audio and control signals over shielded twisted pair CAT6 at distances up to 230 feet (70meters).
Perfect for deploying in classrooms, conference rooms and auditoriums equipped with HDBaseT based projectors and displays.
Note: Please use Shielded Twisted Pair CAT6 for best transmission and zero cross-talk.
<b>features</b>
- HDBASE70POER (Receiver Only) - designed for HDBaseT projectors and HDTV's.
- Extend HDMI/ DVI signals over single CAT6a cable
- Supports resolutions from 1080p/60@48bit to 4Kx2K
- Supports all 3D formats
- High bandwidth up to 10.2 Gbps
- HDCP & EDID compliant
- Bi-directional RS -232 protocol
- Bi-directional IR control
- Built-in LED indicators for signal/ work status
- Mountable aluminum enclosure
- Locking HDMI connector and power supply
- External power supply (100V-240V AC, 50/60Hz)
Note: We recommend using a metal STP connector for RJ-45. The shielded layer of cable must be connected to the connector’s metal shell for zero EMI noise and excellent transmission
