性能
HDCP |
Y |
填补率 |
8.64 billion texels/sec |
DirectX版本 |
10 |
OpenGL版本 |
2.0 |
最高着色模型版本 |
4.0 |
处理器
处理器频率 |
540 MHz |
图形适配器随机存取存储器数字/模拟转换器 |
400 MHz |
流处理器 |
32 |
内存参数
内存带宽(最大) |
12.8 GB/s |
数据宽度 |
128 bit |
内存时钟速度 |
800 MHz |
另外
图形处理器 |
GeForce 8600 GT |
双dvi(互应式数字视频) |
Y |
PX 8600 GT 512MB with hdcp capable, 128-bit memory interface for hi-resolution, opengl 2.0 optimizations and support
Features
NVIDIA Lumenex Engine
- Delivers stunning image quality and floating point accuracy at ultra-fast frame rates.
- 16x Anti-aliasing: Lightning fast, high-quality anti-aliasing at up to 16x sample rates obliterates jagged edges.
- 128-bit floating point High Dynamic-Range (HDR): Twice the precision of prior generations for incredibly realistic lighting effects
HDCP Capable
- Allows playback of HD DVD, Blu-ray Disc, and other protected content at full HD resolutions with integrated High-bandwidth Digital Content Protection (HDCP) support. (Requires other compatible components that are also HDCP capable.)
NVIDIA PureVideo HD technology
- The combination of high-definition video processors and NVIDIA DVD decoder software delivers unprecedented picture clarity, smooth video, accurate color, and precise image scaling for all video content to turn your PC into a high-end home theater.( Feature requires supported video software.)
PCI Express support
- Designed to run perfectly with the next-generation PCI Express bus architecture. This new bus doubles the bandwidth of AGP 8X delivering over 4 GB/sec in both upstream and downstream data transfers.
Dual-Link DVI
- Supports hardwares with awe-inspiring 2560-by-1600 resolution, such as the 30-inch HD LCD Display, with massive load of pixels, requiring a graphics cards with dual-link DVI connectivity.
NVIDIA unified architecture
- Fully unified shader core dynamically allocates processing power to geometry, vertex, physics, or pixel shading operations, delivering up to 2x the gaming performance of prior generation GPUs.
GigaThread Technology
- Massively multi-threaded architecture supports thousands of independent, simultaneous threads, providing extreme processing efficiency in advanced, next generation shader programs.
Dual 400MHz RAMDACs
- Blazing-fast RAMDACs support dual QXGA displays with ultra-high, ergonomic refresh rates up to 2048x1536 85Hz.
NVIDIA Quantum Effects Technology
- Advanced shader processors architected for physics computation enable a new level of physics effects to be simulated and rendered on the GPU—all while freeing the CPU to run the game engine and AI.
Microsoft DirectX 10 Shader Model 4.0 Support
- The standard for today's PCs and next-generation consoles enables stunning and complex effects for cinematic realism.
