端口 & 界面
TV输出 |
Y |
接口类型 |
PCI Express x16 |
NVIDIA Quadro FX 1300 - 128 MB; 256 bits
NVIDIA Quadro FX 1300 by Leadtek supports two single-link DVI-I display connectors, features 128 MB of DDR memory and incorporates theNVIDIA Quadro FX 1300 GPU and the High-Speed AGP to PCI Express Interconnect (HSI). The NVIDIA Quadro FX 1300 delivers industry-leading performance, and advanced features and programmability at the top end of the price/performance segment.
Full 128-Bit Precision Graphics Pipeline
Enables sophisticated mathematical computations to maintain high accuracy, resulting in unmatched visual quality. Full IEEE 32-bit floating-point precision per color component (RGBA) delivers millions of color variations with the broadest dynamic range.
Full-Scene Antialiasing (FSAA)
Up to 8x FSAA dramatically reduces visual aliasing artifacts or aggies?at resolutions up to 1920x1200, resulting in highly realistic scenes.
Next-Generation Vertex & Pixel Programmability
Enables real-time shaders to simulate a wide range of physical effects (such as fresnel effects, chromatic dispersion, reflection, refraction, etc.), and surface properties (such as casting effects, porosity, molded surfaces, etc.).
nView Multi-Display Technology
The nView hardware and software technology combination delivers maximum flexibility for multi-display options, and provides unprecedented end-user control of the desktop experience.
Proven Workstation Graphics Architecture
The NVIDIA Quadro FX architecture takes application performance to new levels by featuring parallel vertex engines, a radically new line engine, the industry's first on-chip vertex cache, and fully programmable pixel pipelines coupled to a high-speed graphics DDR DRAM bus.
12-Bit Subpixel Precision
3x that of the nearest competitive workstation graphics, 12-bit sub-pixel precision delivers high geometric accuracy, eliminating sparkles, cracks, and other rasterization anomalies.
High Precision Dynamic Range Imaging (HPDR) Technology
Sets new standards for image clarity and quality through floating point capabilities in shading, filtering, texturing and blending. Enables unprecedented rendered image quality for visual effects processing. Support for 32-bit floating point precision per component industry exclusive.
Hardware-Accelerated Pixel Read-Back
Greater than 1.0GB/sec. pixel read-back performance delivers massive host throughput, more than 5x the performance of previous generation graphics systems.
PCI Express Support
Designed specifically to take advantage of the next-generation PCI Express bus architecture. This new bus doubles the bandwidth of AGP 8X delivering over 4 GB per second in both upstream and downstream data transfers.
