能量控制
| 功耗（最大） |
4.5 W |
| 支持以太网（PoE） |
Y |
| 输入电压 |
100 - 240 V |
性能
| 最大户外范围 |
30000 m |
| 网上管理 |
Y |
| 支持服务质量（QoS） |
Y |
| 频段 |
5.150 - 5.850 GHz |
| 5 GHz |
Y |
| 运转模式 |
Access point (auto WDS), access point (iPoll 2), station (WDS, iPoll 2), station (ARP NAT) |
| 高功率 |
Y |
| 发射功率 |
29 dBmW |
| 接收机灵敏度 |
-97 - -75 |
| 频道频宽 |
40 MHz |
| 2.4 GHz |
N |
| 以太网的数据传输率 |
10, 100 Mbit/s |
| 调制 |
16-QAM, 64-QAM, BPSK, OQPSK |
| 带宽 |
5.85 GHz |
协议
| 动态主机配置协议服务器 |
Y |
| 动态主机配置协议客户 |
Y |
| 支持网络协议 |
IPv6 |
| 管理协议 |
HTTP(S) GUI, SSH, SNMP read, WNMS, Telnet |
天线
| 天线增益水平（最大值） |
23 dBi |
| 集成天线 |
Y |
| 天线数量 |
1 |
另外
| 包括 AC 适配器 |
Y |
| 数据传输率（最大） |
300 Mbit/s |
IEEE 802.11 a/n, 5.150 - 5.850 GHz, 80000 PPS, 170 Mbps, 29 dBm / 23 dBi, 5/10/20/40 MHz, MIMO 2x2
<b>New Hardware platform</b>
Powerful new generation CPU ensures better performance delivering higher up to 170 Mbps capacity and almost 2 X higher packet per second rate (80000). Narrow (5 and 10 MHz) channel support ensures steady performance in noisy environments. More RAM improves the performance with multiple users connected to a single base-station and larger flash stores a 2nd failover firmware image.
<b>Integrated surge protection</b>
3 kV line to ground and 1 kV line-to-line protection allows operating in a harsh weather conditions and unstable electrical installations.
<b>New OS</b>
New operating system includes all the essential features for point-to-multipoint networks. User interface is built using HTML 5 technology with responsive design. Among the new features there are IPv6 bridge and router support, SSDP and Bonjour device discovery options, flexible traffic shaping and SSTP client. New generation DLB devices are backwards compatible with APC series from Deliberant even when using iPoll protocol. In order to achieve this a new firmware image has to be installed on all APC devices (v7.0 or later).
<b>iPoll 3 – enhanced performance protocol</b>
LigoWave’s iPoll™ PTMP (Point to Multi-Point) proprietary protocol is an innovative solution to eliminate transmission congestion and close cluster interference created in PTMP wireless installations.
