数据传输
| 存储转发 |
Y |
| 交换容量 |
1 Gbit/s |
| 最大数据传输率 |
16 Gbit/s |
联网
| 速率限制 |
Y |
| 链路汇集 |
Y |
| 端口镜像 |
Y |
| 流量控制支持 |
Y |
| 动态主机配置协议客户 |
Y |
| 动态主机配置协议服务器 |
Y |
| 全双工传输 |
Y |
管理功能
| 系统事件日志 |
Y |
| 支持管理信息基本原则 |
MIB-II, Ethernet-Like MIB, P-BRIDGE MIB, Q-BRIDGE MIB, Bridge MIB, RSTP MIB, RMON MIB Group 1,2,3,9 |
| 支持服务质量（QoS） |
Y |
其他功能
| 安装端口 |
1 |
| 无线局域网连接 |
Y |
| 数据传输速度 |
2.5 Mbit/s |
端口 & 界面
| 控制台端口 |
RS-232 |
| 基本交换 RJ-45 以太网端口数量 |
1 |
| DC-IN插口 |
Y |
EDS-518A Series, 16+2G-Port Gigabit Managed Redundant Ethernet Switch
- Industrial Networking Capability
- Turbo Ring (recovery time < 20 ms at full load) and RSTP/STP (IEEE802.1W/D)
- IGMP Snooping and GMRP for filtering multicast traffic from industrial Ethernet protocols
- IEEE802.1Q VLAN and GVRP protocol to ease network planning
- QoS-IEEE802.1p/1Q and TOS/DiffServ to increase determinism
- 802.3ad, LACP for optimum bandwidth utilization
- IEEE802.1X and https/SSL to enhance network security
- SNMP V1/V2c/V3 for different levels of network management
- RMON for efficient network monitoring and proactive capability
- Designed for Industrial Applications
- Bandwidth management prevents unpredictable network status
- Supports ABC-01 (Automatic Backup Configurator) for system configuration back up
- Lock port for authorized only MAC address access
- Port mirroring for online debugging
- Automatic warning by exception through email, relay output
- Digital inputs to integrate sensors and alarms with IP networks
- Automatic recovery of connected device's IP addresses
- Line-swap fast recovery (patented)
- Redundant, dual DC power inputs
- IP30, rugged high-strength case
- Long-haul transmit distance of 40 km or 80 km
- DIN-Rail or panel mounting capability
- Send ping commands to identify network segment integrity
- Redundant 12-45 VDC power inputs and over current protection
