联网
| 布线技术 |
10/100/1000Base-T(X) |
| 支持的协议 |
DHCP, DNS, FTP, HTTP, SNTP, NTP, Telnet, SMTP, SNMPv2, TCP, UDP, IPv4, ICMP, IGMP, IPsec, TAPI, ICS, PPP, CHAP, EAP, PPPoE, PPTP, NetBIOS |
| 以太网的数据传输率 |
10, 100, 1000 Mbit/s |
处理器
| 处理器安装数量 |
1 |
| 处理器高速缓存 |
0.512 MB |
| 处理器光刻 |
45 nm |
| 总线频率 |
12 |
| 处理器运行模式 |
32-bit |
| 处理器插槽 |
Socket F (1207) |
| 步进 |
C0 |
| 核心的处理器数量 |
1 |
| 处理器频率 |
1.6 GHz |
| 总线类型 |
FSB |
| 处理器前端汇流总线 |
533 MHz |
| 处理器高速缓存类型 |
L2 |
| Number of Processing Die Transistors |
47 M |
| 散热设计功耗 (TDP) |
2.5 W |
| 无冲突处理器 |
N |
| 结温 |
90 °C |
| FSB奇偶校验 |
N |
端口 & 界面
| DVI端口 |
Y |
| 串口数量 |
4 |
| RS‐232/422 端口 |
Y |
| PS/2连接埠数量 |
1 |
| Line-in |
Y |
| Line-out |
Y |
| VGA（D-SUB）端口数量 |
1 |
| DC-IN插口 |
Y |
性能
| 主板南桥 |
Intel ICH7M |
| 监视报警功能 |
Y |
存储介质
| 可支持的存储驱动器数量 |
2 |
| 总存储容量 |
2 GB |
| 集成读卡器 |
Y |
| 热插拔驱动器托架 |
Y |
| 硬盘接口 |
Serial ATA II |
处理器的特殊功能
| 执行禁止位 |
Y |
| 热监测技术 |
Y |
| 英特尔®可信执行技术 |
N |
| 英特尔®直接输入/输出硬件辅助虚拟化技术 (Intel® VT-d) |
N |
| 英特尔®超线程技术 |
Y |
| 英特尔®Turbo Boost技术 |
N |
| 英特尔® 增强暂停状态 |
N |
| 增强型英特尔®SpeedStep动态节能技术 |
Y |
| 英特尔®基于需求开关 |
N |
| 支持指令集 |
SSE3, SSE2 |
| 处理器封装尺寸 |
22 mm |
| Processor ARK ID |
36331 |
| 处理器代码 |
SLB73 |
| 英特尔®64 |
N |
| 可选用的嵌入式选项 |
Y |
内存参数
| 内存插槽数量 |
1x SO-DIMM |
| 最大内部存储 |
2 GB |
| 内置存储器 |
1 GB |
| 内存类型 |
DDR2-SDRAM |
| 内存时钟速度 |
533 MHz |
| 内存布局 |
1 x 1 GB |
软件
| 预先安装软件 |
Windows Embedded Standard 2009 |
| 操作系统结构 |
32-bit |
另外
| 主板晶片 |
Intel 945GSE Express |
| Processing die size |
26 mm² |
| 以太网连接器 |
Y |
x86 ready-to-run embedded computer with Intel Atom N270 CPU, VGA, DVI-I, audio, 2 Ethernet LAN ports, 4 serial ports, 6 DIs, 2 DOs, 3 USB ports, 1 CompactFlash slot, 2 hot-swappable storage trays, Windows Embedded Standard 2009, -25 to 60°C operating temperature
The V2416 Series embedded computers are based on the Intel Atom N270 x86 processor and feature 4 RS-232/422/485 serial ports, dual LAN ports, and 3 USB 2.0 hosts. In addition, V2416 computers provide VGA and DVI-I outputs and are compliant with a portion of EN 50155 specifications, covering operating temperature, power input voltage, power surges, ESD, and vibration, making them particularly well-suited for railway and industrial applications.
The CompactFlash socket, SATA connectors, and USB sockets provide the V2416 computers with further reliability, perfect for industrial applications that require data buffering and storage expansion. Most importantly, V2416 computers come with key enhancements for mass storage media, such as two hot-swappable SATA drive trays for convenient and fast storage maintenance, user-programmable LEDs, and an API that simplifies customizing mass storage monitoring and management. Lastly, Moxa's MDM API is also included, giving users a convenient gateway-client model that eases the distributed automation and control of multiple devices by a single host device.
V2416 series computers come pre-installed with a choice of Linux, Windows Embedded Standard 2009, or Windows Embedded Standard 7, giving our customers their choice of software environments for the development of platform applications.
