背板输出端口
| USB 连接器形状 |
USB Type-C, USB Type-A |
| PS/2连接埠数量 |
1 |
| USB3.1（第 2 代3.1）Type-C 端口数量 |
1 |
| USB3.1（第 2 代3.1）Type-A 端口数量 |
1 |
| USB 3.0（第 1代3.1）Type-A 端口数量 |
4 |
| S/PDIF输出接口 |
Y |
| 麦克风/音频输入插孔 |
Y |
| 耳机输出端口 |
1 |
性能
| 音频系统 |
Realtek ALC1150 |
| 英特尔® 极限内存认证标准 （Intel® XMP) |
Y |
| 组件应用 |
PC |
| 主板芯片组系列 |
Intel |
内置输入/输出系统
| 12V 电源接头 |
Y |
| 前面板接头 |
Y |
| M.2 (M) 插槽数量 |
1 |
| SATA Express 连接器数量 |
1 |
| 前面板音频接头 |
Y |
| 机箱防盗接口 |
Y |
| CPU风扇接口 |
Y |
| PS电源接口 （8针） |
Y |
| USB 2.0接口 |
2 |
| SATA III连接器数量 |
10 |
| USB 3.0（第 1代3.1）连接器 |
2 |
| TPM（可信任安全平台模组）接口 |
Y |
| ATX电源接头 |
Y |
内存参数
| 内存插槽类型 |
DIMM |
| 内存通道支持 |
Quad |
| 支持的内存类型 |
DDR4-SDRAM |
| 內存插槽数量 |
8 |
| 最大内部存储 |
128 GB |
| 无缓冲内存 |
Y |
| 错误更正代码 |
Y |
| 无错误检测和更正 |
Y |
基本輸出輸入系統/BIOS
| 清除CMOS跳线 |
Y |
| BIOS内存大小 |
32 MB |
| 基本输入输出系统类型 |
UEFI AMI |
扩展槽
| PCI Express X16（Gen 3.x）插槽 |
3 |
| PCI Express x1（Gen 2.x）插槽 |
2 |
另外
| 主板晶片 |
Intel X99 |
| 以太网路(RJ-45)连接接口数量 |
1 |
| 以太网连接器 |
Y |
Intel Core i7, LGA2011-3, Intel X99, 8 x DDR4, Realtek ALC1150, 305 x 244mm, ATX
<b>MAKING YOUR LIFE EASIER IS OUR BUSINESS</b>
The PRO Series motherboards fit in any PC. Quality you can trust with top performance and clever business solutions are key aspects of these motherboards. Make your life easier and boost your business with the super stable, reliable and long-lasting PRO Series motherboards.
<b>Unmatched memory performance and stability</b>
With traditional memory design the memory signals are often distorted by electromagnetic signals from other components, making the system perform slower or become unstable. MSI introduces DDR4 Boost technology with optimized traces and fully isolated memory circuitry. This design ensures the memory signals stay pure for optimal performance and stability.
<b>Turbo U.2 On Board</b>
Turbo U.2 connector delivers performance up to 32 Gb/s and allows support for next gen 2.5-inch SSDs using the U.2 connector.
<b>TURBO M.2</b>
Delivering speeds up to 32Gb/s using Gen3 x4, Turbo M.2 is more than 5 times faster than a regular SATA III connection! Enjoy a blazing fast system boot up and insanely fast loading of applications and games.
<b>FAST STORAGE WITH SATA EXPRESS</b>
SATA Express offers a solution in high speed storage through PCI-Express, providing more bandwidth for the latest generation SSDs up to 16 Gb/s.
<b>ENHANCED CPU OVERVOLTAGE PROTECTION</b>
Onboard overvoltage protection prevents overvoltage and short-circuit damage of the CPU and other components. A red LED near the 24 pin CPU power connector let you know that overvoltage protection is activated for easier troubleshooting.
<b>WHQL CERTIFIED. WINDOWS 10 READY.</b>
Benefit from great compatibility and a worry-free user experience when using Microsoft Windows 8 / 8.1 or Windows 10 with MSI PRO Series motherboards.
MSI is world’s first motherboard manufacturer to receive official Microsoft Windows 10 WHQL certification. With a true testament to compatibility and performance, the MSI R&D team ensures a worry-free experience when using the latest version of Microsoft Windows on any MSI PRO Series motherboard.
