9-channel, 2.4 GHz, 132 x 64, 2100 mAh
<b>Further advantages:</b>
M-LINK 2.4 GHz transmission technology
Transmitter features proven integrated M-LINK 2.4 GHz transmission technology
Binding and reduced-power modes for range-checking are easy and convenient to activate. Receiver FAIL-SAFE positions can be set from the transmitter using a menu.
<b>16-channel operation</b>
A special feature of the ROYAL SX 16 is its sixteen fully proportional channels. Four of these are auxiliary channels; these always operate with full servo travel, and are intended for supplementary functions. The RX-16-DR pro M-LINK sixteen-channel receiver is required in order to use the auxiliary channels.
<b>Downlink channel / Telemetry</b>
If you are using a telemetry-capable receiver, the receiver battery's actual voltage is displayed on the transmitter screen. If the voltage falls to a (user-variable) minimum voltage an audible signal provides a warning that the receiver pack is discharged. The radio link quality (LQI) can also be displayed on the transmitter screen as a % value without additional sensors.
<b>An extra safety enhancement!</b>
It is also possible to have up to fifteen items of telemetry data from the model displayed on the transmitter screen, depending on the sensors connected to the receiver, e.g. voltage, current, temperature, etc. Typical applications: motor temperature, flight pack voltage, motor current.
<b>Low latency / high resolution</b>
A digital interface to the RF module ensures extremely fast, accurate, high-resolution transmission of the control signals. The ROYAL SX M-LINK operates with a servo frame rate of 14 ms in twelve-channel mode (alternatively 21 ms in sixteen-channel mode) with 12-bit resolution (3872 steps). Switchable Normal / Fast Response: the frame rate can be changed to 21 ms in case 14 ms is too fast for the servos in the model.
<b>Quick conversion</b>
If you wish to continue to use your old stock of receivers exploiting conventional FM technology (PPM, M-PCM), that presents no problems: the ROYAL SX M-LINK can be converted in less than a minute - even at the flying site. The HFM4 M-LINK 2.4 GHz RF module with 2.4 GHz aerial is simply swapped for the existing FM RF module, and the long telescopic transmitter aerial replaced.
