设计
| 支持的主板外形 |
ATX, Micro-ATX, Mini-ATX |
| 3.5" 托架数量 |
3 |
| 侧窗 |
Y |
| 2.5" 托架数量 |
4 |
| 最大显卡长度 |
364 mm |
| 最大CPU散热器高度 |
161 mm |
| 格式要素 |
Midi-Tower |
| 类型 |
PC |
冷却
| 支持的顶部风扇直径 |
120, 140 mm |
| 最大前部风扇 |
2 |
| 支持的后部风扇直径 |
120 mm |
| 最大后部风扇 |
1 |
| 最大顶部风扇 |
1 |
| 安装的顶部风扇 |
1x 120 mm |
| 安装的后部风扇 |
1x 120 mm |
| Front radiator fan sizes supported |
120, 140 mm |
端口 & 界面
| USB 3.0(第 1代3.1)Type-A 端口数量 |
2 |
Source 340 Elite Midi Tower Case - Black/Blue
Expanding on the S340’s renowned durability, the S340 Elite features a tempered glass panel to showcase builds with crisp clarity. The top IO panel has been optimized with an HDMI port and additional USB ports for a streamlined VR experience. It includes a magnetic cable management puck to conveniently store VR or audio headsets with fast and flexible mounting access. The S340 Elite is strong, compact, and takes the S340 chassis to new heights.
- Steel chassis and tempered glass construction
- Cable management optimized for a simple and hassle-free build
- Streamlined VR access with HDMI and USB 3.0 from the top IO
- Easy-to-use headset and VR cable management puck
- Full Kraken Series cooler support up to 280mm
- Integrated PSU shroud with three SSD mounts
- Fully filtered, easy-to-remove intake
