Product types: AV Receiver, Network Receiver
Series: Onkyo TX-NR
Speaker configuration: 9.2
Connections
Analog audio inputs: 1x MM Phono In (Cinch/RCA, Stereo), 6x LINE In (Cinch/RCA, Stereo)
analog audio output: Zone 2 (LINE Out, Cinch/RCA, Stereo)
digital audio inputs: 1x S/PDIF IN (Cinch/RCA coaxial), 1x S/PDIF IN (TOS-Link optical)
HDMI ports: 2x HDMI Out, 7x HDMI In
Video Connections: 1x Component IN, 2x S-Video IN
Preamp outputs: 2x Subwoofer (Cinch/RCA), 1x Stereo Pre Out (Cinch/RCA)
Front Connections: 1x Measurement Microphone (Setup Mic), Headphone Output, Aux In (3.5mm Jack, Stereo), HDMI Input
Data connections: 1x Network (Ethernet), 2x USB 2.0
additional connection: Antenna connection
Audio
Audio functions: aptX, aptX HD
Dolby Formats: Dolby Atmos, Dolby Height Virtualization, Dolby Surround
DTS Formats: DTS:X, DTS Virtual:X, DTS Neural:X
THX Formats: THX Certified
Number of listening zones: 2
Video
Supported Resolutions: 8K (4320p), 4K (2160p), 1080p
Video Functions: HDR10, HDR10+, HLG (Hybrid Log Gamma), Dolby Vision, BT.2020 support
Connectivity
Network functions: Audio streaming, App control, Network standby
Wireless transmissions: Chromecast, Bluetooth, AirPlay 2, Sonos Connect, Wi-Fi, Roon Ready, DTS Play-Fi
Streaming Services: Amazon Music, Deezer, Spotify, Tidal, TuneIn
USB Interface: yes
Functions
automatic measurement: yes
Calibration systems: AccuEQ, Dirac Live
with remote control: yes
Reception areas: FM, DAB+, AM
Number of station presets: 40
Ppower supply
Power consumption in operation: 570 Watt
Power Consumption Standby: 1,7 Watt
Smart Home
Voice Assistants: Amazon Alexa, Google Assistant, Apple Siri
Additional features
Dimensions: 435 x 174 x 380 mm
Weight: 10,4 kg
Housing property: Metal
