技术细节
| 遵守工业标准 |
IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3u |
| 处理器安装数量 |
1 |
| 处理器频率 |
66 MHz |
协议
| 管理协议 |
CLI, TFTP, SNMP MIB II |
| 数据链路协议 |
Ethernet, Fast Ethernet |
联网
| 声音功能 |
H.323v4, SIPv2, DTMF |
| 支持数据传输率 |
10 / 100Mbps |
能量控制
| 接受频率 |
50 / 60 Hz |
| 输入电压 |
100 - 240 V |
4 FXO VoIP Gateway
- Up to 8 FXS and/or FXO ports—Compact, reliable stand-alone VoIP gateway with different port options. Supports simultaneous voice or fax calls on all ports. (note: Patton does not carry an 8-FXO unit at the present time).
- Advanced Local Call Switching—Virtual interfaces and routing tables provide industry leading flexibility in call handling programming. Local call switching, soft fallback to alternative routes. Simultaneously connects to multiple SIP services/IP PBXs.
- Complete SIP and T.38 support—Supports the complete range of industry standard VoIP: SIP, H.323, T.38 fax, fax and modem handling, DTMF relay. Codecs G.729, G.723, etc.
- Easy Management & Provisioning—Web-based management, SNMP, command line interface. Automated mass provisioning for efficient large-scale deployments.
- Outstanding Interoperability—Proven integration for voice and T.38 fax with 3CX, Asterisk, PingTel and other leading IP PBX systems and soft switch vendors.
- Supported by SmartNode Redirection Service: A free service enabling zero-touch mass deployments for Service Providers and Distributors with auto-provisioning servers.
<b>Overview</b>
The business-class SmartNode 4110 VoIP Media Gateway supports up to eight transparent phone calls and leverages VoIP for carrier and corporate access. Connecting to any analog phone, fax, or PBX, the SN4110 is an effective and flexible solution for toll-bypass, remote/branch office voice connectivity, and enhanced carrier services.
The SN4110 series is the perfect choice for phone-to-IP connectivity supporting up to 8 FXS ports or a combination of 4 FXS and 2 or 4 FXO ports. With its FXS analog ports the SN4110 connects to any legacy telephone or PBX and provides dial-tone, ringing, caller-ID and other services. When equipped with FXO ports, the local PSTN can be accessed enabling local calling and enhanced toll-bypass applications while using a single connected telephone. Flexible call integration allows per-port telephone numbers, programmable call progress tones, and distinctive ringing. With Telephony-over-IP (ToIP) call switching, calls can automatically be routed to the PSTN or the IP network while providing flexible numbering plans and end-to-end feature transparency. PPPoE, DHCP, and VLAN offers universal IP connectivity and optional IPSEC VPN with AES/3DES guarantees secure voice over the public network.
Patton's SmartNode 4110 delivers the legacy phone interfaces, service transparency, and flexible PSTN integration for true converged packet voice.
<b>Applications</b>
<b>Remote Office/Branch Office Voice Extension and Access</b>
In enterprise networks, transparent access to PBX features while using existing equipment is key to low-cost operations. Now, instead of installing a separate PBX at the remote office, the SmartNode 4110 is able to provide transparent extension while simultaneously connecting multiple locations. The extensions can be managed centrally and benefit from PBX services such as calling groups, least cost routing, and call forwarding. PSTN access allows local calls to be processed without using corporate remote PBX resources. Additionally, the corporate PBX can break-out and bypass any long distance charges by using the remote office for the local gateway.
