Sharkoon M25-W Midi-Tower Black

Sharkoon M25-W Midi-Tower Black

EAN: 4044951019335
MPN: 4044951019335
发送方式:
交货来源:
德国
更新价格... 📣 询问价格 Не поставляется
运输成本:
От

凡购买和价格 (Advertising *)

顶部
в наличии
* Alle Preise inkl. der jeweils geltenden gesetzlichen Mehrwertsteuer, ggfs. zzgl. Versandkosten. Alle Angaben ohne Gewähr. Preisänderungen sind in der Zwischenzeit möglich.

技术特点

顶部

冷却

最大前部风扇 2
最大后部风扇 1
最大顶部风扇 3
前部风扇安装 2x 120 mm
支持的后部风扇直径 120 mm
安装的后部风扇 1x 120 mm

设计

最大CPU散热器高度 167 mm
最大显卡长度 400 mm
类型 PC
防灰尘过滤器 Y
照明 Y
最大PSU长度 205 mm
格式要素 Midi-Tower
3.5" 托架数量 3
5.25" 托架数量 2
扩展插槽数 7
2.5" 托架数量 2

电源

电源 N
电源位置 Bottom

人体工程学

改良型电缆管理 Y

端口 & 界面

USB 3.0(第 1代3.1)Type-A 端口数量 2
M25-W - ATX, Acrylic, Mini-ITX, Micro-ATX, ATX, 2xUSB 3.0, 6.5kg The Sharkoon M25 series stands for minimalist design ATX Midi Tower, which is particularly impressive due to its versatile installation possibilities and its tidy appearance, both inside and out. The M25-W, available in both black and white, is especially deep. Its acrylic side panel displays what gamers care about, which stays well-lit thanks to the LED fan mounted on the rear panel of the case. However, the innovative distinguishing feature of the elegant case is not just its appearance, but also its rich sound: Thanks to its integrated 7.1 sound card, demanding gamers benefit not only from the perfect coordination of their team but also from bombastic surround sound.

<b>Integrated 7.1 Surround Sound</b>
The integrated 7.1 sound card is connected to the front connectors of the case, in which two parallel audio sources can be used: While a headset can be operated through the audio connector on the front panel, additional speakers can be used on the audio connectors via the on-board sound card. The included audio software for Windows allows additional 7.1 audio signal individual equalizer functions with effects as well as microphone boost settings. The settings can be stored then bundled on the PC for later use in four different profiles. An unlimited number of configurations can be created to each of the four profiles. The integrated 7.1 sound card conveniently connects on the mainboard via the internal USB port.

<b>Systematic Arrangement</b>
The special construction of the case interior offers enormous possibilities for discreet installation of various components. Cabling can be inconspicuous and hidden, therefore not affecting airflow inside the case. The power supply and up to three 3.5" hard drives can be installed on the bottom of the case inside the tunnel, therefore not detracting from the appearance. The air vents on the tunnel, side and top, ensure optimal cooling of hard drives. The mainboard and the remaining components enjoy perfect cabling thanks to the cable outlets. Installing a new heat sink for the CPU is extremely easy thanks to an opening in the mainboard tray. A tower cooler up to 16.7 cm in height can be installed. Maximum length for graphics cards is 40 cm; power supplies with a length of up to 20.5 cm. Three pre-installed dust filters protect installed hardware from contamination. For cleaning, they are easily removable and placed back on. Another pre-installed filter is also on the top panel, which can be quickly removed thanks to its magnetic fastener.

<b>Cableless Front Panel Design</b>
Another big advantage of the M25-W is its cableless front panel design. The front panel can be easily removed without needing to disconnect any cables. This facilitates the installation of a 5.25" or 3.5" drive tremendously.

<b>Optimal Preparation for Perfect Airflow</b>
The front panel has on its right and left, hidden behind the mesh panel, numerous air inlets, which ensure a supply of cold air. Pre-installed in the front panel, behind the dust filter, are two 120 mm fans. Alternatively, there are suitable holes for two 140 mm fans. For water cooling, the M25-W offers the possibility of a 240 mm or 280 mm radiator, with a total height of 5.0 cm including fan, to be operated in the front of the case. On the rear panel of the case a 120 mm LED fan is pre-installed. If desired, three 120 mm or two 140 mm fans can be installed underneath the magnetic dust filter on the top panel. Oval hole cutouts offer excellent opportunities for perfect positioning of fans or radiators.

<b>Modern Front Connectors</b>
Two USB 3.0 and two Audio ports in the front panel provide quick access to connect the most important peripheral devices. The USB 3.0 ports are connected via a 19-pin mainboard connector, including alternative USB 2.0 access, to ensure backward compatibility with older mainboards.

<b>Versatile Mounting Options</b>
For optical drives, the M25-W offers two 5.25" drive bays with automatically locking tool-free device installation. By means of the enclosed 5.25" to 3.5" bay cover, for example, a card reader can be quickly and easily installed into one of the two 5.25" drive bays. If necessary, two 2.5" HDD/SSDs can be incorporated instead. If more space is needed, the screwed in drive bays can be completely removed. In the bottom of the case, up to two 3.5" hard drives, or two 2.5" HDD/SSDs decoupled, are installed by means of a mounting frame. Space for another 3.5" drive is also available on the bottom of the case. Behind the mainboard tray of the M25-W, and on the tunnel, are two mounts for 2.5" drive bay trays. Thus allowing, via convenient thumbscrews, installation of up to two 2.5" HDD/SSDs.
