数据传输
| 支持数据传输率 |
10/100 Mbps |
| 最大数据传输率 |
0.1 Gbit/s |
其他功能
| 连通的液晶显示器 |
Y |
| 网路功能 |
Ethernet, Fast Ethernet |
| 支持的协议 |
CSMA/CD |
联网
| 自动 MDI / MDI - X 检测功能 |
Y |
| 全双工传输 |
Y |
端口 & 界面
| 基本交换 RJ-45 以太网端口数量 |
8 |
| DC-IN插口 |
Y |
8-Port 10/100Mbps PoE Switch
TPE-S44 8-Port Smart Switch integrates Power over Ethernet (PoE) and network management features into a cost effective and scalable solution. The TPE-S44 reduces equipment cost by delivering data and power over existing network cable infrastructure.
-Reduces equipment cost by delivering data and power over existing network cables.
-4 PoE and 4 standard 10/100Mbps ports.
-Flow Control for Full-Duplex mode.
-IEEE 802.3af Power over Ethernet (PoE) Standard Compliant.
-8 x 10/100Mbps Auto-Negotiation and Auto-MDIX Fast Ethernet RJ45 Ports.
-Built-in 4 PoE Ports (Port 1 ~ Port 4).
-Supports PoE Power Maximum 15.4 watts for each POE port.
-Supports PoE Powered Device (PD) classification identify.
-Full Wire-Speed Non-Blocking Reception and Transmission.
-Store and Forward Switching Method.
-96Kbytes RAM Data Buffer and 1K entries MAC Address Table.
-Extensive Diagnostic LED´s on the Front Panel.
-IEEE 802.3x Flow Control for Full-Duplex Mode; Back Pressure Flow Control for Half-Duplex Mode.
-5-year limited warranty.
