显示器
| 绿色同步 |
Y |
| 独立h/v同步 |
Y |
| 显示器尺寸 |
22 " |
| 垂直扫描范围 |
50 - 76 Hz |
| 触摸屏技术 |
Capacitive |
| 对比度（动态） |
50000000:1 |
| 响应时间 |
7 ms |
| 复合同步 |
Y |
| 对比度 |
1000:1 |
| 显示器分辨率 |
1920 x 1080 pixels |
| 视角，水平 |
178 ° |
| 视角，垂直 |
178 ° |
| 显示器亮度 |
250 cd/m² |
| Full HD |
Y |
| 显示器 |
IPS |
| 显示类型 |
TFT |
能量控制
| 功耗（节能） |
19 W |
| 功耗（一般操作） |
25 W |
| 功耗（最大） |
28 W |
| 交流电（AC）输入电压 |
100-240 V |
| 交流电（AC）输入频率 |
50/60 Hz |
| 电源类型 |
AC |
端口 & 界面
| 包含电缆 |
AC, Audio (3.5mm), HDMI, USB |
| 耳机输出端口 |
1 |
| DisplayPort 数量 |
1 |
| USB 3.0（第 1代3.1）Type-A 端口数量 |
2 |
| HDMI端口数量 |
1 |
| VGA（D-SUB）端口数量 |
1 |
重量和尺寸
| 含底座尺寸（宽 x 深 x 高） |
490.3 x 298.8 x 129.7 mm |
| 重量（含底座） |
3600 g |
| 深度 |
47.3 mm |
| 重量 |
3600 g |
| 宽度 |
490.3 mm |
| 高度 |
298.8 mm |
性能
| 扬声器数量 |
2 |
| 同步接触点（Windows7） |
10 |
| 连接到PC |
Y |
| RMS的额定功率 |
6 W |
| 触控技术 |
Multi-touch |
| 内置扬声器 |
Y |
人体工程学
| VESA 安装支架 |
Y |
| VESA 安装系统兼容界面 |
100 x 100 mm |
| 倾斜调整 |
Y |
| 墙壁支架 |
Y |
| 倾角 |
20 - 70 ° |
包装数据
| 包装盒厚度 |
371 mm |
| 包装重量 |
4700 g |
| 包装盒宽度 |
550 mm |
| 包装盒高度 |
114 mm |
另外
| 水平扫描范围 |
24 - 82 kHz |
| 显示器对角线（公制） |
55.88 cm |
| 运行温度范围（T - T） |
0 - 40 °C |
22”, 1920 x 1080, 1000:1, 7ms, TFT, 178 º / 178 º , 21,5”, 50000000:1, LED, 250 cd/m2, 7H, USB 3.0, HDMI, VGA, DisplayPort, 3W x2, 19W, 22W, 25W, 28W, 100-240 V, 50/60Hz, OSD, 0 º - 40 º C, 20%-90%, VESA, 24-82 kHz, 50-76 kHz, 20 º -70 º, 4.7 kg, 3.6 kg, 3.6 kg
10-Point Projected Capacitive Touch
Touch screens with projected capacitive touch can recognize up to 10 points of simultaneous contact, allowing for a highly accurate and ultra-responsive touch experience. With smooth and responsive touch capabilities, this touch display is ideal for home entertainment, office work, education, and commercial use.
SuperClear IPS Panel Technology
Enjoy accurate and vivid colors with consistent levels of brightness no matter the vantage point. With SuperClear IPS panel technology, this monitor delivers the same image quality whether you are looking at the screen from above, below, the front, or the side.
Frameless Design
Say goodbye to the thick, clunky plastic frames set over the edges of traditional monitors. This monitor features a frameless edge-to-edge glass faceplate with an ultra-slim bezel beneath the glass. With its sleek, eye-catching design, this elegant monitor looks as good as it performs.
Versatile Connectivity
DisplayPort, HDMI, and VGA inputs give you the freedom to connect your monitor to a variety of devices.
Durable, Scratch-resistant Screen
This touch display is designed with a durable, protective glass faceplate. This provides increased scratch protection to ensure durability, as well as a consistent, high-quality touch experience in high-traffic areas such as educational settings, or other public environments where the touch display can be used as a kiosk.
Stable Bookstand Design
A stable, integrated bookstand design makes it easy to adjust the angle of this display for a better user experience. The display can tilted or laid completely flat on a tabletop for a more comfortable work environment.
Enhanced ViewingComfort
Flicker-Free technology and a Blue Light Filter help to eliminate eye strain from extended viewing periods.
Cross-platform Compatibility
Cross compatibility with a wide range of operating systems include Windows 10, and certain Android and Linux versions.
VESA-CompatibleMount
Mount the monitor as you see fit using its convenient VESA-compatible mount design.
3-year LimitedWarranty
Have peace of mind in the quality and reliability of your ViewSonic monitor—backed by one of the industry’s best pixel performance policies and a 3-year limited warranty.
