端口 & 界面
| 串口数量 |
2 |
| RJ-45输入端口 |
1 |
| RJ-45输出端口 |
1 |
| Number of HDMI outputs |
1 |
| 音频（左、右声道）输出 |
1 |
| HDMI输入 |
1 |
| 串口类型 |
RS-232 |
| USB 端口数量 |
2 |
| DC-IN插口 |
Y |
技术细节
| 带宽 |
2.25 Gbit/s |
| 可支持的电缆类型 |
Cat5 |
| 最大传输距离 |
70 m |
| 类型 |
AV transmitter & receiver |
重量和尺寸
| 发射器尺寸（宽x深x高） |
105 x 88 x 25 mm |
| 发射器重量 |
300 g |
| 接收器的重量 |
380 g |
| 接收器尺寸（宽 x 深 x 高） |
108 x 106 x 25 mm |
能量控制
| 外接电源转接器 |
Y |
| 电流 |
3 A |
| 工作电压 |
12 V |
1 x HDMI, 1 x RS-232 - 1 x HDMI, 1 x RS-232, CAT5, 70m
Using Valens Semiconductor’s powerful HDBaseT chipsets, Vision’s TC2-HDBT products squeeze uncompressed HDMI, RS-232 and power – all over one CAT5e cable up to 100m long! Sold as a transmitter and receiver set for standalone applications, or as separate parts for integration into a system which already has HDBT transmitters or receivers.
RS-232
Bi-directional RS-232 is supported for controlling remote display equipment. The TC2-HDBT an especially powerful solution for any AV application; staging, rental, digital signage, and corporate installations.
Audio Output
The receiver has an audio decoder built in which takes stereo audio from the HDMI signal and converts it to useful analogue format.
Full HD
The HDBT solution transmits full v1.4 spec HDMI with no compression. 1080p@60Hz@48 bits, 4K x 2K. Full 3D support and HDCP compliant.
PoE
When used as a standalone set the proprietary “power over ethernet” means only one power supply is required and can be used at either end – you choose.
EDID Management
Dip switches on the side can be adjusted to set various EDID (extended display identification data) scenarios.
Skew-free
TC2-HDBT products do not require EQ adjustment.
Techconnect Twist
Vision offer a full suite of products which carry HDMI, RS-232, VGA, and USB over twisted-pair (CAT5) cable.
Vision Quality
Enclosed in robust metal chassis’ with mounting ears included, Vision has used tried and tested industrial design to ensure stable heat management for reliable performance.
