能量控制
| 接受频率 |
50 - 60 Hz |
| 输入电压 |
110 - 240 V |
技术细节
| 下行链路功率（最大） |
30.2 / 30.5 dBmW |
| 上行链路功率（最大） |
0.43 / 0.63 mW |
| 下行链路增益 |
19 dB |
| 上行链路频率范围 |
824 - 894 / 1850 - 1990 MHz |
| 数据网络 |
GPRS, 3G |
| 下行链路频率范围 |
824 - 894 / 1850 - 1990 MHz |
| 上行链路增益 |
19 dB |
| 类型 |
Indoor cellular signal booster |
The In-Line Signal Booster is designed to be used by professional installers in larger buildings to provide an additional 17dB gain to compensate for signal loss due to a long cable run or use of taps or splitters to accommodate multiple antennas. The Inline Booster is installed between a Wilson indoor signal booster unit, like the AG Pro Installer, and that booster's inside antenna. Optimally the In-line Booster is installed after long runs of cable and/or taps and splitters to compensate for signal loss. The Inline Booster can be installed in the middle of a cable run or near the inside antenna, as needed.
Separate adjustable gain controls provides up to 17dB gain to compensate for signal loss. Compatible with all 800 & 1900 MHz cellular networks – 2G & 3G (expect push-to-talk). Configurable with a variety of Wilson signal boosters, antennas and components to fit virtually any large building installation. FCC type accepted, Industry Canada certificated. Natural up-sell for residential and commercial installers. Maintains strong, reliable signal even after long cable runs. Allows installation of multiple inside antennas with minimal signal loss. Simplifies complex installations in larger buildings
