KREILING KR 9 FEB HQ Satellitenantennen-Zubehör

CLASS A, 3 GHz, 118 x 55 x 50 mm KREILING INLINE amplifier KR 20 IL is an amplifier suitable for the frequency range 950-2200 MHz (SAT-ZF). The amplification in this frequency range is linear 20dB. The power supply is remote-fed by the receiver antenna cable .The diplexer KR EW 3 has 2 inputs (1 x 5-860 MHz; 1 x 950-2250 MHz) which are brought together to 1 output (1 x 5-2250 MHz). Terrestrial signals are brought together with a SAT-signal, to be continued on one cable. Up tp 500 mA can be passed. Using the attenuation controler KR DR 20 a too high performance can be damped. This is possible in the terrestrial ansd SAT-frequency range from 45 – 2300 MHz. Because of its small dimensions and the 2 F-sockets KR DR 20 can be easily installed everywhere
