性能
| 主板元件 |
Micro ATX |
| 音频系统 |
ALC887 |
| 组件应用 |
PC |
内存参数
| 可支持内存时钟速度 |
1066, 1333 MHz |
| 无错误检测和更正 |
Y |
| 內存插槽数量 |
4 |
| 最大内部存储 |
32 GB |
基本輸出輸入系統/BIOS
| BIOS内存大小 |
32 MB |
| 清除CMOS按钮 |
Y |
| ACPI的版本 |
2.0a |
其他功能
| 操作特性 |
WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE |
| 控制器接口类型 |
VIA VT6415 |
内置输入/输出系统
| USB 2.0接口 |
4 |
| S/PDIF输出端口 |
Y |
| ATX电源接头 |
Y |
| 风扇电源接头 |
Y |
| TPM（可信任安全平台模组）接口 |
Y |
| SATA III连接器数量 |
2 |
| SATA II连接器数量 |
4 |
| 周边（莫仕）电 源连接器（4针） |
1 |
| PS电源接口 （8针） |
Y |
| 并行接口 |
Y |
| COM连接器数量 |
1 |
| 机箱防盗接口 |
Y |
| 机箱风扇接头数量 |
1 |
| 前面板音频接头 |
Y |
扩展槽
| PCI 插槽 |
1 |
| PCI Express x16 插槽 |
2 |
| PCI Express × 1插槽 |
1 |
| PCI Express插槽版本 |
2.0 |
背板输出端口
| PS/2连接埠数量 |
2 |
| 耳机输出端口 |
3 |
| S/PDIF输出接口 |
Y |
| HDMI端口数量 |
1 |
| VGA（D-SUB）端口数量 |
1 |
另外
| 主板晶片 |
Intel H67 |
| 以太网路(RJ-45)连接接口数量 |
1 |
Intel Socket 1155, Core i7/Core i5/Core i3, Intel H67, uATX, 4x DIMM Max. 32GB DDR3 Non-ECC, 4x SATA 3.0 Gb/s, 2x SATA 6Gb/s, 10x USB 2.0
LGA1155 Intel® Sandy Bridge Processor Ready
This motherboard supports the latest Intel® Sandy Bridge processors in the LGA1155 package, with memory and PCI Express controllers integrated to support 2-channel (4 DIMM) DDR3 memory and 16 PCI Express 2.0 lanes. This provides great graphics performance. Intel® Sandy Bridge processors are among the most powerful and energy efficient CPUs in the world.
Intel® H67 Chipset
The Intel® H67 Express is the latest single-chipset design that supports the new socket 1155 Intel® Core™ i3/Core™ i5/Core™ i7 2nd generation processors. It improves performance by utilizing serial point-to-point links, allowing for increased bandwidth and stability. Additionally, the H67 comes with 2 SATA 6Gb/s and 4 SATA 3Gb/s ports for faster data retrieval, doubling the bandwidth of current bus systems. Moreover, Intel® H67 Express Chipset also supports iGPU function.
Quad-GPU CrossFireX Support!
Flexible Multi-GPU solutions, Your Weapon of Choice!
P8H67-M brings you the multi-GPU choice of ATI Quad-GPU CrossFireX. The motherboard features the most powerful Intel H67 platform to optimize PCIe allocation in multiple GPU configurations. Expect a brand-new gaming style you’ve never experienced before!
Native SATA 6Gb/s Support
The Intel® H67 Chipset natively supports next-generation Serial ATA (SATA) storage interface, this motherboard delivers up to 6.0 Gb/s data transfer rates. Additionally, get enhanced scalability, faster data retrieval, double the bandwidth of current bus systems.
ASUS Exclusive Features
GPU Boost
Go to the Limit with iGPU Level Up!
GPU Boost accelerates the integrated GPU for extreme graphics performance. The user-friendly interface facilitates flexible frequency adjustments. It easily delivers stable system-level upgrades for every use.
MemOK!
Any Memory is A-OK!
MemOK! quickly ensures memory boot compatibility. This remarkable memory rescue tool requires a mere push of a button to patch memory issues. MemOK! determines failsafe settings and dramatically improves system boot success. Get your system up and running in no time!
TurboV
Easy, Real-Time O.C. Tunings
Feel the adrenaline rush of real-time OC-now a reality with the ASUS TurboV. This easy OC tool allows you to overclock without exiting or rebooting the OS; and its user-friendly interface makes overclock with just a few clicks away. Moreover, the ASUS OC profiles in TurboV provides the best O.C. settings in different scenarios.
Auto Tuning
Auto Tuning is an intelligent tool that automates overclocking to achieve a total system level up. This tool also provides stability testing. Even O.C. beginners can achieve extreme yet stable overclocking results with Auto Tuning!
