端口 & 界面
音频(左、右声道)输出 |
1 |
DC-IN插口 |
Y |
VGA(D-SUB)端口数量 |
2 |
DisplayPort 数量 |
2 |
技术细节
最高操作距离 |
300 m |
Full HD |
Y |
外接电源转接器 |
Y |
视频接口类型 |
VGA |
VE300RQ - A/V receiver
<b>The VE300 A/V Over Cat 5 Extender system is designed to integrate seamlessly into installations with the ATEN VM0808T Cat 5 A/V Matrix Switch. With ATEN’s exclusive Deskew technology, the VE300 allows you to extend the distance between the A/V source and the display monitor by up to 150 m with a resolution of 1600x1200 (for the VE300R), or up to 300 m with a resolution of 1280x1024 (for the VE300RQ).</b>
It is able to accomplish this by means of a local transmitting unit (the VE300T), connected to the remote receiving unit (either the VE300R or VE300RQ), using Cat 5e twisted pair cable. Because it allows access to the audio/video source over large distances, the VE300 is ideal for installations such as construction sites, factory floors, control and security centers, where the system equipment can reside in a safe and secure location, while the display is conveniently located in public view.
To provide optimum video quality over large distances, the VE300RQ supports RGB delay tuner functionality – allowing you to manually synchronize the RGB signals. It also provides a line synchronization function that corrects color phase and timing errors that occur over long distance transmissions, and stores the settings.
