Technical details
| Number of connectors |
12 |
| Fiber mode structure |
Multi-mode |
| Category |
OM4 |
| Duplex |
Y |
Packaging content
| Quantity per pack |
1 pc(s) |
Closet Connector Housing (CCH) Module, pigtailed, LC Connectors, Duplex, 12 F, 50 µm multimode (OM4)
Corning closet connector housing (CCH) pigtail modules accommodate all industry-standard connector adapter types including the LC, ST® compatible, SC, SC duplex, FC and MT-RJ, as well as the keyed LC. Like LANscape® solutions panels, the modules are the same size for 6-, 8-, 12-, 16- and 24-fiber capacities. Each module provides strain-relief for the pigtail and offers the advantage of greater protection to the cables and connectors being installed when the pigtails will be routed and spliced in a separate housing. Available with both ribbon and 900 um tight-buffered MIC® cable types, each CCH module is factory terminated and tested. Each module is shipped assembled with adapters and connectorized pigtails installed to the customer’s specifications.
