Technical details
| Transfer rate |
90 MB/s |
| Interface |
SATA |
| Number of simultaneous copies |
11 |
1:11 mSATA / micro SATA SSD duplicator, LCD, 90 MB/sec, 10 Kg
- Duplicate up to eleven (11) copies of micro SATA HDD/SSD or mSATA SSD
- The supported media can be mixed in the target slots - great for transferring content from one type of media to different type of media
- Media slot is designed for direct loading of Micro SATA hard drive or SSD
- mSATA SSD into the media slot via micro SATA - mSATA adapter (model: ADMS18SA). Twelve adapters are included
- Copy CFast or CF media with optional micro SATA adapters (ADCFASTMS or ADMSCF)
- Completely standalone operation with no computer or software required
- Maximum copying speed up to 90 MB/sec. Actual speed depends on the performance of the media
- Drive sanitization :
- SECURE ERASE - HDD duplicator sends a WIPE command to the hard drive. This command fills 00 string to entire HDD (this feature may not be supported by some mSATA SSD or flash media)
- OVERWRITE - One pass, 3 passes and 7 passes 5220.22-M. The duplicator writes a string of pattern over the entire disk one time, three times or seven times. 5220.22-M is the DoD standard for drive sanitization
- OS independent
- LCM control module provides a rich set of robust advanced configuration options (click Full LCD console feature list in this duplicator)
- Green LED for both source and destination slots to indicate media access ( Supported only on media with drive access signal)
