Wireless LAN features
| Top Wi-Fi standard |
IEEE 802.11ac |
| Wi-Fi standards |
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.11ac |
| WLAN data transfer rate (max) |
300 Mbit/s |
| Wi-Fi band |
Dual-band (2.4 GHz / 5 GHz) |
Ethernet LAN features
| Ethernet LAN interface type |
Gigabit Ethernet |
| Ethernet LAN data rates |
10, 100, 1000 Mbit/s |
Management features
| Web-based management |
Y |
| Reset button |
Y |
Other features
| Input current |
1 A |
| Frequency band |
2.4 & 5 GHz |
| Flash memory |
8 MB |
| Internal memory |
64 MB |
| Mobile network connection |
N |
Additionally
| Ethernet LAN connection |
Y |
| Ethernet LAN (RJ-45) ports quantity |
4 |
1200Mbps 802.11ac, WAN/4xLAN, 5Ghz/2.4GHz, White
<b>802.11ac 1200Mbps Concurrent Dual Band</b>
The AC-1200R use the next generation WiFi technology that allows the router to connect with both 5Ghz and 2.4GHz wireless device at speed up to 1200Mbps. It is also completely compatible with legacy 11n, 11a, 11g, and 11b devices.
<b>50% Greater Coverage</b>
Hi-Power radios and MIMO antennas enable the AC-1200R to provide up to 1.5 times the coverage comparing to normal wireless routers. That means faster speed at further distance.
<b>Digital Home Network</b>
The AC-1200R’s dual radio system is designed for digital home applications. The 5GHz network is less vulnerable to interference; therefore, it is suitable for video streaming and game networks. The 2.4GHz radio provides a separate network for computers, tablet PC, and smart phones.
In addition, the AC-1200R includes 5 Gigabit LAN ports which allow maximum speed connection with NAS or PC.
<b>Free Central management software</b>
The free AirLive Central software can discover your router automatically, let you change settings, or even upgrade firmware in a very easy to use interface. You can even do group configuration and firmware upgrades multiple AirLive products such as AC-1200Rs, AC.TOP, and N.TOP. Please check the video below for details.
<b>Independent Radio Operation</b>
The AC-1200R inherited the capability of our popular G.DUO and A.DUO access points. Each radio can operate in different modes for up to 5 different wireless modes. You can configure the AC-1200R to suit different operation environment.
<b>Detachable Antennas</b>
5 operations with detachable antennas allow the AC-1200R to use in various indoor + outdoor application, such as sharing a remote internet connection signal from outside.
