Performance
| Waveform |
Sine |
| Audible alarm(s) |
Y |
| UPS topology |
Standby (Offline) |
| Audible alarm modes |
Alarm when on battery, Low battery alarm, Overload alarm |
Power
| Input operation voltage (max) |
139 V |
| Input operation voltage (min) |
92 V |
| Power supply input frequency |
50/60 Hz |
| Surge energy rating |
354 J |
| Output power capacity |
900 VA |
| Output operation voltage (max) |
120 V |
| Output frequency regulation |
50/60 Hz |
| Output power |
480 W |
Ports & interfaces
| AC outlet types |
NEMA 5–15R |
| Cable length |
1.52 m |
| AC outlets quantity |
9 AC outlet(s) |
Battery
| Battery technology |
Sealed Lead Acid (VRLA) |
| Battery recharge time |
8 h |
| Battery life (max) |
5 year(s) |
Operational conditions
| Operating relative humidity (H-H) |
0 - 95% |
| Storage temperature (T-T) |
-15 - 45 °C |
| Storage relative humidity (H-H) |
0 - 95% |
Weight & dimensions
| Depth |
105 mm |
| Weight |
4100 g |
| Width |
327 mm |
| Height |
139 mm |
| Package depth |
168 mm |
| Package weight |
4400 g |
| Package width |
416 mm |
| Package height |
196 mm |
Certificates
| RoHS compliance |
Y |
| Energy Star certified |
Y |
Design
| Form factor |
Mini tower |
| Display |
LED |
Additionally
| Colour of product |
Black |
| Operating temperature range (T-T) |
0 - 40 °C |
900 VA, 480 W, 120 V, 6 x NEMA 5-15R(Battery Backup), 3 x NEMA 5-15R(selector_surgetitle), 92 - 139 V, 50/60 Hz, 354 J, 1.52 m, Black
Adjustable voltage sensitivity
Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications.
Audible alarms
Provides notification of changing utility power and UPS power conditions
Automatic self-test
Periodic battery self-test ensures early detection of a battery that needs to be replaced.
Battery failure notification
Provides early-warning fault analysis on batteries enabling timely preventive maintenance
Building Wiring Fault Indicator
This LED informs users of potentially dangerous wiring problems in the wall circuit.
Cold-start capable
Provides temporary battery power when the utility power is out.
Disconnected battery notification
Warns when a battery is not available to provide backup power.
Hot-swappable batteries
Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
Simple battery replacement
Increases UPS availability by allowing quick, easy battery replacement.
Transformer Block Spacing
Connect bulky transformer block plugs without covering up other outlets.
USB connectivity
Provides management of the UPS via a USB port (not available on all models).
