Ethernet LAN features
Cabling technology |
10/100Base-T(X) |
Ethernet LAN interface type |
Fast Ethernet |
Ethernet LAN data rates |
10, 100 Mbit/s |
Security
VPN support |
IPSec Pass-Through\nPPTP Pass-Through\nL2TP Pass-Through\nPPTP server |
MAC address filtering |
Y |
Software
Linux operating systems supported |
Y |
Mac operating systems supported |
Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.10 Yosemite, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
Wireless LAN features
Top Wi-Fi standard |
IEEE 802.11n |
WLAN data transfer rate (max) |
300 Mbit/s |
Wi-Fi standards |
IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Other features
Internal memory |
128 MB |
Flash memory |
128 MB |
Rack mounting |
N |
Input current |
1.75 A |
Frequency band |
2.4 GHz |
USB version |
2.0 |
USB ports quantity |
2 |
Antenna
Antenna type |
Internal |
Antennas quantity |
2 |
Management features
Reset button |
Y |
Web-based management |
Y |
Ports & interfaces
RJ-11 ports quantity |
1 |
DC-in jack |
Y |
Additionally
Ethernet LAN connection |
Y |
On/Off switch |
Y |
AC adapter bundled |
Y |
Ethernet LAN (RJ-45) ports quantity |
5 |
IEEE 802.11 b/g/n, 300 Mbps, VDSL2/ADSL2+/ADSL2/ADSL, 4 x Fast Ethernet, 2 x USB 2.0, 147 x 205 x 66 mm, 370 g
DSL-N17U Wireless-N300 Gigabit ADSL/VDSL Modem Router
- Dual-purpose wireless router and DSL modem with both Ethernet and DSL internet connection (WAN) ports.
- Compatible with ADSL2/2+, ADSL, VDSL2, fiber and cable services for complete future-proofing.
- Gigabit Ethernet ports for the fastest, most reliable internet performance.
- Dual multi-purpose USB ports support file sharing, printer sharing and media streaming.
- ASUS AiCloud lets you access, sync, share and stream data from your home network to any internet-connected PC, Android or iOS device.
Wins PCMag Readers’ Choice Award for the fourth straight year (2012, 2013, 2014 and 2015).
The ASUS DSL-N17U ADSL/VDSL wireless modem router is stylish, truly multi-functional, and has reliable performance. It can connect to the internet using either the Ethernet or DSL WAN (Wide Area Network) ports, allowing customers to use it as a either a modem router or a standalone wireless router. Compatible with ADSL2/2+, ADSL, VDSL2, fiber and cable services.
Equipped with powerful hardware NAT acceleration and built-in Gigabit Ethernet, the DSL-N17U gives you full Gigabit internet performance, with a WAN-to-LAN throughput performance of over 900 Mbps.
Two USB 2.0 ports allow the DSL-N17U to share printers and scanners over a network, and it can also operate as high-speed NAS (Network Attached Storage) device when external storage is connected.
The easy-to-use ASUSWRT graphical user interface unlocks the power of the DSL-N17U giving robust control to optimize your network for you. 30-second set-up and easy traffic management means even network newbies can enjoy its sophisticated features, while power users will love its Download Master, IPv6 support, multiple wireless SSIDs and secure VPN access.
Two WAN ports for DSL and Ethernet offer double the choice
The DSL-N17U has two WAN (Wide Area Network) ports, allowing it to be used as a standalone router when not operating as a DSL modem router. You can choose which mode suits your needs at any time, reducing cost and clutter by not having to buy separate power-consuming devices. Whether for a basic home setup or a full wireless network, this dual-WAN design gives you total flexibility.
Enhanced signal range and stability
ASUS AiRadar intelligently improves wireless connections by using exclusive ASUS RF fine-tuning. This ensures extended coverage, dynamic data speed increases, and enhanced stability.
Gigabit Internet browsing with hardware NAT
Equipped with a powerful hardware NAT acceleration engine and built-in Gigabit Ethernet, the DSL-N17U gives you full Gigabit performance. Its WAN-to-LAN throughput performance is over 900 Mbps, which is more than 4.5 times that of traditional software-based NAT Gigabit routers. This reduces the possibility of bottlenecks on fast internet connections.
Add external storage, printers, and other devices to your network
Make DSL-N17U your media and device center. With built-in two USB ports, connect external storage drives, printers, scanners and many other USB-enabled devices to share with your networked PCs. Having your devices networked, lets you access them easier than ever before.
Robust control and optimization with DSL ASUSWRT
With the DSL-ASUSWRT dashboard UI, setup, monitor, and control network applications all in one intuitive area. The whole-new dashboard interface lets you manage all clients and settings via a single graphical interface, and provides 1-click updates.
ASUS AiCloud – Your world on demand
ASUS AiCloud keeps you connected to your data wherever and whenever you have an internet connection. It links your home network and online web storage service and lets you access it through the AiCloud mobile app on your iOS or Android smartphone or through a personalized URL in a web browser.
Download and stream anywhere
Download Master and enhanced media server let you download and play multimedia files stored on router-attached USB storage on a wide range of compatible devices such as PC, pad, PS4, Xbox, and smart TV. Download Master can also download files while your PC is turned off, and allows you to manage and monitor download status remotely.
Better online multitasking at up to 300,000 sessions
Massive online multitasking at up 300,000 concurrent data sessions gives you 20 times the capacity of mainstream routers, allowing for great performance with no slowdown even during heavy traffic sessions. Multiple downloads occur at the same time to create a smoother user experience. More data sessions translate into quicker and buffer-less HD streaming plus lag-free online gaming even while you download content, so you can do more without compromising your online lifestyle.
VPN server and VPN client support
DSL-N17U offers a simple VPN server and VPN client setup to access a home network or the internet privately and securely. Easily set up a VPN server with PPTP protocol support with no need for paid VPN services or a dedicated VPN server. DSL-N17U also turns your network-connected devices into VPN-enabled clients via PPTP and L2TP protocols without additional VPN software required.
