Ports & interfaces
| S/PDIF in port |
Y |
| CD/AUX audio in |
Y |
| Host interface |
PCI-E |
| Headphone outputs |
2 |
| Microphone in |
Y |
| S/PDIF out port |
Y |
Audio
| Line-out Signal-to-Noise Ratio (SNR) |
120 dB |
| Audio quality |
24 bit |
| Internal |
Y |
| Frequency range |
10 - 46000 Hz |
| Digital-to-Analog Conversion (DAC) |
24-bit/192KHz |
Xonar HDAV1.3, 24 bits, 192 kHz, 120 dB SNR
Enjoy 100% Blu-Ray Quality Audio with HDMI 1.3 Compliance and Video Enhancement
- Full-HD Audio/Video digital output
- HDMI v1.3a compliance
- Non-downsampled 192kHz Blu-Ray audio
- Splendid HD Video enhancement
- Complete Dolby True HD & DTS HD
The Essential Component for all HTPC Builders
Without Xonar HDAV1.3, Blu-Ray Disc goes down to DVD Quality on PC!
With industry-leading PAPS & AACS compliance, now you get TRUE Blu-Ray Audio Quality when played on your PC system,ONLY with Xonar HDAV1.3!
Powerful Bundle: ArcSoft TotalMedia™ Theatre
Best Performance on HD Content Playback
ArcSoft TotalMedia™ Theatre supports playback of all three Blu-ray disc video formats: High Definition MPEG-2, AVC, and VC1´s well as all kinds of other High Definition (HD) content: WMV HD, Quicktime HD, DivX HD, and H.264 HD.
Next Generation Home Theatre
ArcSoft TotalMedia™ Theatre fully supports the next generation audio formats used in Blu-ray discs: LPCM, AC-3, DD+, and MLP.
HDCP Support
ArcSoft TotalMedia™ Theatre includes full support for High-Bandwidth Digital Content Protection (HDCP), a form of digital rights management.
NOTE: Bundled version supports high-definition audio decoding and playback, including DTS-HD, Dolby TrueHD, and Dolby Digtial Plus. Advanced HDMI 1.3 HD audio pass-through feature will be available soon via TMT patch update.
NOTE: Operating Systems supported by TotalMedia Theatre are Windows VISTA 32/64 and XP 32
Re-Defines Hi-Fi PC Audio
Hyper Grounding Circuitry Design
With Hyper Grounding, digital and analog signals are clearly separated, and 4-layer PCB board is used to make sure only the cleanest signal passed to the sensitive components.
New Generation HTPC Standard
PAPS with AACS Compliance for Original Quality BD-Audio Output
With upgradeable PAPS on Xonar HDAV1.3, new lossless compressed digital audio formats, such as Dolby® TrueHD and DTS-HD Master Audio™ will be supported for theater-like, professional sound quality, and full flavor output at 96K or 192K is guaranteed.
Certificated HDMI 1.3 Support
Deeper Color
HDMI 1.3a supports 30-bit, 36-bit and 48-bit (RGB or YCbCr) color depths, for stunning rendering of over one billion colors!!
Broader Color Range
Next-generation "xvYCC" color space supports 1.8 times as many colors as existing HDTV signals!
Exclusive Splendid HD Video Processor
Presents True HD video for HTPC
The Splendid HD Video Processor uses proprietary Splendid video engine to increase color performance and enhance edges for a more brilliant, crisper image--even on high-definition content at ZERO CPU loading impact.
Video Up-Sampling
For lower resolution images, Splenidid HD recovers clarity which improves consumer experiences when viewing legacy content on today´s advanced television systems.
Multi-range Video Enhancing
For HD contents, Splendid HD increases color performance and enhances edges for a more brilliant, crisper image. Such as better visual contrast without flickering issue, and much vivid color than reality
Swappable OPA Socket
The new swappable OPAMP socket design on Xonar HDAV allows customers to change to other high-quality OPAMPs for preferred analog sound color
High Performance Component Onboard
Xonar HDAV1.3 invents its fantastic audio quality with proprietary ASUS AV200, high quality oversampling digital to analog converters (Burr-Brown PCM1796, 123dB SNR), National Semiconductor LM4562 OP AMP, and analog-to-digital converter (Cirrus Logic CS5381, 120dB SNR).
