Atto FibreConnect 1612-D00 Managed Fast Ethernet (10/100) 1U Silver

Atto FibreConnect 1612-D00 Managed Fast Ethernet (10/100) 1U Silver

EAN: 603175007951
MPN: FCSW-1612-D00
🚚 Select the country of delivery:
Delivery from:
Germany
Updating price ... 📣 Send Price inquiry Не поставляется
Delivery cost & estimated delivery time:
От
days

Where to buy and prices (Advertising *)

On Top
в наличии
* Alle Preise inkl. der jeweils geltenden gesetzlichen Mehrwertsteuer, ggfs. zzgl. Versandkosten. Alle Angaben ohne Gewähr. Preisänderungen sind in der Zwischenzeit möglich.

Technical specifications

On Top

Management features

Multicast support Y

Networking

Auto-sensing Y
Port mirroring Y
Link aggregation Y
Full duplex Y

Power

Input voltage 85 - 264 V
Power consumption (max) 57 W

Operational conditions

Non-operating altitude 0 - 12000 m
Operating altitude 0 - 3000 m
Heat dissipation 195 BTU/h

Ports & interfaces

Basic switching RJ-45 Ethernet ports type Fast Ethernet (10/100)
SFP+ module slots quantity 24
Compatible memory cards Not supported
Console port RJ-45

Design

Form factor 1U
Rack mounting Y

Security

IP-MAC-Port binding Y
MAC address filtering Y

Data transmission

Switching capacity 16 Gbit/s
Number of trunks 8
Latency (10-100 Mbps) 700 µs
Number of multicast groups filtered 255
24 x SFP+, 16 Gb/s, 1U, USB, RJ-45, 10/100, 19'' rack, 7.82 kg, 437.64 x 43.18 x 443.23 mm, 195 BTU/hr, 85 - 264 V, 47 - 63 Hz The ATTO FibreConnect™ 1612-D00 16Gb/s Fibre Channel switch provides flexibility, simplicity, and enterprise-level functionality for small to mid-range SANs to enable high performance and low latency collaborative workflows. It is available in a 12-port configuration with a single power supply and an optional 12-port expansion to extend your switch to 24 ports. FibreConnect is an affordable solution for consolidating storage on a SAN, which increases productivity and allows multiple users to more efficiently share resources.

The FibreConnect™ 1612-D00 switch is easy to deploy, manage and integrate into both new and existing SANs while delivering exceptional performance and functionality. It combines auto-sensing 2, 4, 8, and 16Gb/s Fibre Channel throughput with features that greatly enhance workflow processes. With Ports on Demand, scalable from 12 to 24-ports, FibreConnect enables organizations to grow their storage networks when necessary in a non-disruptive manner.
