Black Box VWP-2110 4K Ultra HD video conferencing system

4K, 6xUSB 2.0, 2x3.0, 482x500x175mm, 25kg Product Features

- Create advanced, massive video walls to improve situational awareness and operator response time.
- Designed for use in command centers, control rooms, and other 24/7 mission-critical operations centers.
- Freely position any video input or loaded content anywhere on the video wall.

Details

- Easy to use – drag, drop, resize, and scale.
- Scalable: supports up to 64 video outputs and 100s of inputs.
- Designed for fast switching and 24/7 operations.
- 800 W redundant power supply ensures continuous operation.
- Supports true 4K at 60 Hz input and output via DisplayPort.
- Choose from a wide range of input cards for any video format.
- System works with all common and modern video formats.
- Decodes and displays standard-based IP video streams (H.264, VC-1, MPEG2, and MJPEG).
- Mix live capture, IP streams, and local media into one application.
- Provides real-time support for multiple wall control operators.
- Run software on the video wall control processor.

Mission-critical applications Create large-scale video walls to visualize mission-critical information and to improve situational awareness, decision making, and response times in the following applications:

- Broadcast and media
- Defense
- Public safety
- Industry

The chassis

The heart of the system is the 11-slot controller chassis. It incorporates a switched fabric backplane and provides 11 PCIe slots with x16 connector for use with Radian video capture or graphics cards. Each slot is capable of providing 8 GB/s bi-directional bandwidth. The chassis also includes a single board computer featuring an Intel Core i7 processor with up to 16GB of DDR3 memory and on-board graphics. Each system comes with dual high-quality, server-grade hard drives setup with RAID.

Any Video, Anywhere

Freely position content from any source, anywhere on the video wall. Then you can easily drag, drop, resize, and scale in real time.

Scalable

Multiple chassis configurations enable you to expand the system. Scale up by adding cards, not PCs.

Any video format

Radian supports a wide range of video input cards: composite, component, SDI, HDMI, VGA, DP, DVI, and IP. It decodes and displays standard-based IP video streams (H.264) and supports 4K at 60 Hz transmission via DisplayPort. It’s also designed to display uncompressed video with no latency for faster operator response times.

Redundant power

The Chassis includes two hot-swappable 800 Watt redundant power supplies for seamless failovers.

Management

Web-based management is done from the included software from any PC over the network. The optional Video Wall Control Software enables remote control of the video wall layout, inputs, and positioning of elements.

An integrated solution—ships fully assembled

Radian is a hybrid hardware and software solution. It’s part of a complete solution that includes the chassis, graphics cards, video capture cards, expansion cards, and software. To help you get the right combination of chassis and cards for your specific application, Black Box offers free application engineering and 24/7 free tech support. Talk to one of our technical experts and we’ll design a solution for you. And, we’ll ship the chassis fully loaded with cards and software.

This product includes:

- Radian chassis, 11-slot
- Mouse
- Keyboard
- Software Installation Suite
- (2) Power Cables
