Display | LCD |
---|---|
Rack capacity | 2U |
Form factor | Rackmount/Tower |
Battery capacity | 9 Ah |
---|---|
Hot-swap battery | Y |
Battery recharge time | 3 h |
Battery voltage | 12 V |
Typical backup time at half load | 7 min |
Typical backup time at full load | 3 min |
Cold start | Y |
Number of batteries supported | 6 |
Waveform | Sine |
---|---|
Noise level | 40 dB |
Number of phases | 1 |
UPS topology | Line-Interactive |
Automatic Voltage Regulation (AVR) | Y |
Input operation voltage (max) | 288 V |
---|---|
Input operation voltage (min) | 176 V |
Efficiency | 97% |
Emergency Power Off (EPO) | Y |
Output voltage THD | 10% |
Power supply input frequency | 45/65 Hz |
Output power capacity | 3000 VA |
Crest factor | 3:1 |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Output power factor | 0.9 |
Output voltage regulation | +-5% |
Output power | 2700 W |
Operating relative humidity (H-H) | 0 - 95% |
---|---|
Operating altitude | 0 - 1500 m |
Depth | 600 mm |
---|---|
Weight | 29500 g |
Width | 438 mm |
Height | 86.5 mm |
USB 2.0 ports quantity | 1 |
---|---|
AC outlets quantity | 8 AC outlet(s) |
Colour of product | Black |
---|---|
RS-232 port | 1 |
Ethernet LAN (RJ-45) ports quantity | 1 |
Operating temperature range (T-T) | 0 - 40 °C |
