Power
| Power consumption (max) |
50 W |
| AC input voltage |
100-240 V |
| AC input frequency |
50/60 Hz |
Networking
| Cable types supported |
Cat5, Cat5e, Cat6a |
| VLAN support |
Y |
| Auto MDI/MDI-X |
Y |
| Link aggregation |
Y |
| Networking standards |
IEEE 802.3ab, IEEE 802.3an, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
| 10G support |
Y |
| Full duplex |
Y |
Data transmission
| MAC address table |
1600 entries |
| Latency (10 Gbps) |
10 µs |
Packaging data
| Manual |
Y |
| Rack mount kit |
Y |
Management features
| Switch layer |
L2 |
| Quality of Service (QoS) support |
Y |
| Reset button |
Y |
| Web-based management |
Y |
| Switch type |
Managed |
Optical fiber
| Transmission distance (max) |
0.1 km |
Ports & interfaces
| Basic switching RJ-45 Ethernet ports quantity |
12 |
| Basic switching RJ-45 Ethernet ports type |
10G Ethernet (100/1000/10000) |
| Copper ethernet cabling technology |
100BASE-TX, 1000BASE-T, 10GBASE-T |
Operational conditions
| Operating relative humidity (H-H) |
10 - 85% |
Weight & dimensions
| Depth |
230 mm |
| Weight |
2400 g |
| Width |
330 mm |
| Height |
44 mm |
Design
| LED indicators |
Activity, Link, Power, Speed |
| Certification |
VCCI A, FCC / IC A, UL, CE, CB |
| Form factor |
19U |
| Rack mounting |
Y |
Power over Ethernet (PoE)
| Power over Ethernet (PoE) |
N |
Additionally
| Colour of product |
Black |
| Transfer rate (Mbps) |
120000 Mbit/s |
| Jumbo Frames support |
Y |
| Operating temperature range (T-T) |
0 - 50 °C |
12 x 100M/1000M/10G Full-Duplex, 802.3az, 120Gbit/s, QoS, Auto-MDIX, 2.57kg
High speed switching for SMB
10Gigabit Layer2 Switches
Buffalo’s BS-XP series of 10GbE switches offers an easy, cost-effective and energy-efficient way to extend your business network at blazing speeds. Plug and play installation requires no additional software or configuration; simply plug your network-ready devices into one of the available Ethernet ports. Each AUTO-MDIX port automatically detects and configures the correct connection while optional jumbo frame support and full duplex operation provide maximum performance.
Along with 802.3az Green Ethernet technology, the BS-XP series includes intelligent Power Control, an energy conservation feature that monitors the activity status of each port to reduce the total power consumed. Its durable, metal chassis is equipped with holes for wall-mounting or rubber feet for easy placement on a desktop.
With 10GbE speeds, eco-minded operation, performance-minded features and a lifetime warranty, Buffalo’s BS-XP series of switches is a perfect network extension for your business.
