Performance
| Throughput |
1.9 Gbps |
| Receiver sensitivity |
2.4 GHz\n802.11b: -86 dBm 11Mbps\n802.11g: -74 dBm 54 Mbps\n802.11n(HT20): -71 dBm MCS7\n802.11n(HT40): -68 dBm MCS7\n\n5 GHz\n802.11a: -90 dBm 6 Mbps\n802.11a: -75 dBm 54 Mbps\n802.11ac(HT20): -63 dBm MCS9\n802.11ac(HT40): -60 dBm MCS9\n802.11ac(HT80): -58 dBm MCS9 |
| VLAN support |
Y |
| Automatic channel selection |
Y |
| Number of WLAN connections (max) |
21 |
| Ethernet LAN data rates |
10, 100, 1000 Mbit/s |
| Wireless isolation |
Y |
| 2.4 GHz |
Y |
| 5 GHz |
Y |
| Auto Wireless Distribution System (WDS) |
Y |
| Wi-Fi Multimedia (WMM)/(WME) |
Y |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u |
| Internal memory |
256 MB |
| Flash memory |
128 MB |
| Bandwidth |
5 GHz |
| Spread spectrum method |
DSSS |
| Quality of Service (QoS) support |
Y |
| Reset button |
Y |
| Firmware upgradeable |
Y |
| Certification |
UL 60950-1, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, FCC Part 15.247, 15.407, RSS-210, EN 300.328, EN 301.893, AS/NZS 4268.2003, FCC 15.107 + 15.109, ICES-003, EN 301.489-1 + -17 |
| Number of users |
200 user(s) |
| Modulation |
16-QAM, 64-QAM, 256-QAM, BPSK, OFDM, QPSK |
| Web-based management |
Y |
| Syslog |
Y |
Ports & interfaces
| WAN connection |
Ethernet (RJ-45) |
Packaging content
| Cables included |
LAN (RJ-45) |
| Quick start guide |
Y |
| Mounting kit |
Y |
Antenna
| Integrated antenna |
Y |
| Antenna type |
PIFA |
| Antenna gain level (max) |
1.99 dBi |
| Antennas quantity |
6 |
Design
| Placement |
Ceiling, Table, Wall |
| Internal |
N |
| Cable lock slot |
Kensington |
| LED indicators |
Y |
Security
| Security algorithms |
HTTPS, SNMP, SSID, WDS, WPA, WPA2 |
| Number of SSID support |
16 |
Protocols
| Management protocols |
SNMP v3, Bonjour |
| DHCP client |
Y |
| Supported network protocols |
NTP, HTTP/HTTPS, IPv6 |
Weight & dimensions
| Depth |
230 mm |
| Weight |
778 g |
| Width |
230 mm |
| Height |
40 mm |
Power
| Power over Ethernet (PoE) |
Y |
| Power consumption (max) |
18 W |
Operational conditions
| Storage temperature (T-T) |
-20 - 70 °C |
| Operating relative humidity (H-H) |
10 - 85% |
| Storage relative humidity (H-H) |
5 - 90% |
Additionally
| Colour of product |
White |
| Transfer rate (Mbps) |
600 Mbit/s |
| Packaging type |
Box |
| On/Off switch |
Y |
| Ethernet LAN (RJ-45) ports quantity |
2 |
| Operating temperature range (T-T) |
0 - 40 °C |
802.11ac, 1.9Gbps, 2.4 GHz, 5.0 GHz, 2x LAN Gigabit Ethernet, Wi-Fi, White
Get High Performance and More Coverage
Connect more devices, run more apps, and still keep your network more efficient all at affordable price. Now you can, with our WAP571 wireless access point with 802.11ac technology.
Features and Capabilities
Get exceptional performance, faster connection, and wider coverage on your mobile devices. The WAP571 access point has built-in controller software for managing multiple access points. Its intuitive web-bases configuration allows you to set it up in just minutes.
The Cisco WAP571 access point offers:
- Concurrent dual-band radio support up to 1.3 Mbps on a 5.0-Ghz radio, and 600 Mbps on a 2.4-Ghz radio to make the most of capacity and coverage
- 3x3 MIMO with three spatial streams on both 5.0 GHz and 2.4 GHz allows for maximum performance
- Single Point Setup, a controller-less technology, simplifies the deployment and management of multiple access points, without requiring additional hardware
- A two-Gigabit Ethernet LAN interface can enable a high-speed uplink to the wired network and also link aggregation support to increase the overall bandwidth between the two ports
- A captive portal facilitates highly secure, customized guest access with multiple rights and roles
